HT7350-1
Linear Voltage Regulator IC Positive Fixed 1 Output 250mA SOT-89
SOT-89ROHS CompliantActive
250mA LOW POWER LDO
- Manufacturer
- TDSEMIC
- Manufacturer part #
- HT7350-1
- Store part #
- C22466409
- Package / case
- SOT-89
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,810 in stock
#C22466409
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹9.12 | ₹91.20 |
| 100+ | ₹7.24 | ₹724.00 |
| 300+ | ₹6.31 | ₹1,893.00 |
| 1,000+ | ₹5.61 | ₹5,610.00 |
| 5,000+ | ₹5.04 | ₹25,200.00 |
| 10,000+ | ₹4.76 | ₹47,600.00 |
10 × ₹9.12
₹91.20
excl. GST
₹107.62 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
HT7350-1
₹91.20 for 10 + GST
Specifications
- Output Voltage
- 5V
- Number of Outputs
- 1
- Operating Temperature
- -35℃~+80℃@(Ta)
- Supply Current (Iq)
- 1.5uA
- Output Configuration
- Positive
- Operating Voltage
- 24V
- Output Current
- 250mA
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.152 g
Overview
HT73XX-1 is a low dropout linear regulator utilizing CMOS technology. It delivers an output current of 250mA and supports a maximum input voltage of 24V. Several fixed output voltage options are available, ranging from 3.0V to 5.0V. CMOS technology ensures low dropout voltage and low quiescent current characteristics.
Applications
- Battery-powered devices
- Communication equipment
- Audio/video devices
Key features
- Low power consumption
- Low dropout voltage
- Low temperature coefficient
- Maximum input voltage: 24V
- Typical quiescent current: 1.5μA
- Output current: 250mA
- Output voltage accuracy: ±2%
- Package types: SOT23-3, TO92, SOT89
