IPS70R1K4CEAKMA1
N-Channel 700V 5.4A 53W Through Hole TO-251-3-11
TO-251-3-11ROHS CompliantActive
MOSFET N-CH 700V 5.4A TO-251-3-11
- Manufacturer
- Infineon
- Manufacturer part #
- IPS70R1K4CEAKMA1
- Store part #
- C3289107
- Package / case
- TO-251-3-11
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
15 in stock
#C3289107
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹262.92 | ₹262.92 |
| 10+ | ₹224.59 | ₹2,245.90 |
| 30+ | ₹200.69 | ₹6,020.70 |
| 100+ | ₹176.14 | ₹17,614.00 |
| 500+ | ₹165.16 | ₹82,580.00 |
| 1,500+ | ₹160.43 | ₹2,40,645.00 |
1 × ₹262.92
₹262.92
excl. GST
₹310.25 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,500 per tube
IPS70R1K4CEAKMA1
₹262.92 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+150℃
- Drain to Source Voltage
- 700V
- Output Capacitance(Coss)
- 18pF
- Current - Continuous Drain(Id)
- 5.4A
- Ciss-Input Capacitance
- 225pF
- Pd - Power Dissipation
- 53W
- RDS(on)
- 1.4Ω@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 10.5nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3.5V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 1,500 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.33 g
Overview
CoolMOS is a revolutionary technology for high voltage power MOSFETs, designed according to the superjunction (SJ) principle. CoolMOS CE is a price-performance optimized platform enabling to target cost sensitive applications in Consumer and Lighting markets by still meeting highest efficiency standards. The new series provides all benefits of a fast switching Superjunction MOSFET while not sacrificing ease of use and offering the best cost down performance ratio available on the market.
Applications
- Adapter
- LCD & PDP TV
- Indoor lighting
Key features
- Extremely low losses due to very low FOM Rdson*Qg and Eoss
- Very high commutation ruggedness
- Easy to use/drive
- Pb-free plating, Halogen free mold compound
- Qualified for standard grade applications
