L4940D2T5-TR
5V Positive Fixed D2PAK Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
D2PAKROHS3 CompliantActive
1.5V Ultra-Low Dropout Voltage Regulator IC
- Manufacturer
- ST
- Manufacturer part #
- L4940D2T5-TR
- Store part #
- C2802520
- Package / case
- D2PAK
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
98 in stock
#C2802520
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹190.71 | ₹190.71 |
| 10+ | ₹157.62 | ₹1,576.20 |
| 30+ | ₹139.55 | ₹4,186.50 |
| 100+ | ₹119.08 | ₹11,908.00 |
| 500+ | ₹109.94 | ₹54,970.00 |
| 1,000+ | ₹105.80 | ₹1,05,800.00 |
1 × ₹190.71
₹190.71
excl. GST
₹225.04 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
L4940D2T5-TR
₹190.71 for 1 + GST
Specifications
- Output Voltage
- 5V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+150℃@(Tj)
- Supply Current (Iq)
- 5mA
- Output Configuration
- Positive
- Operating Voltage
- 17V
- Output Current
- 1.5A
- Features
- Thermal shutdown;Short Circuit Protection;Reverse polarity voltage protection
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.938 g
Overview
The L4940 series of three-terminal positive regulators is available in TO-220 and D²PAK packages and with several fixed output voltages, making it useful in a wide range of industrial and consumer applications. Thanks to their very low input/output voltage drop, these devices are particularly suitable for battery-powered equipment, reducing consumption and prolonging battery-life. Each type employs internal current limiting, anti-saturation circuit, thermal shutdown and safe area protection.
Key features
- Precise 5, 8.5, 12 V outputs
- Low dropout voltage (450 mV typ. at 1 A)
- Very low quiescent current
- Thermal shutdown
- Short-circuit protection
- Reverse polarity protection
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | L7805ABD2T-TR#C86206ST · TO-263-2 | ST | TO-263-2 | 68,340 | ₹38.53 · 68,340 in stock | View |
| LD1086D2T50TR#C157456ST · TO-263-2 | ST | TO-263-2 | 150 | ₹2,490.55 · 150 in stock | View | |
 | L7805 TO-263#C54430182KTP · TO-263 | KTP | TO-263 | 515 | ₹32.90 · 515 in stock | View |
 | L7805CD2T(MS)#C20538905MSKSEMI · TO-263 | MSKSEMI | TO-263 | 40 | ₹34.12 · 40 in stock | View |
 | HT7805ASZ#C5158906HTCSEMI · TO-263 | HTCSEMI | TO-263 | 5 | ₹41.21 · 5 in stock | View |
