STDatasheet (PDF)
LD1117V33C
3.3V Positive Fixed TO-220 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
TO-220ROHS3 CompliantActive
Adjustable and Fixed Low Dropout Positive Voltage Regulators
- Manufacturer
- ST
- Manufacturer part #
- LD1117V33C
- Store part #
- C672117
- Package / case
- TO-220
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,983 in stock
#C672117
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹85.31 | ₹85.31 |
| 10+ | ₹70.54 | ₹705.40 |
| 50+ | ₹64.24 | ₹3,212.00 |
| 100+ | ₹56.21 | ₹5,621.00 |
| 500+ | ₹52.75 | ₹26,375.00 |
| 1,000+ | ₹50.79 | ₹50,790.00 |
1 × ₹85.31
₹85.31
excl. GST
₹100.67 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 50 per tube
LD1117V33C
₹85.31 for 1 + GST
Specifications
- Output Voltage
- 3.3V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃
- Supply Current (Iq)
- 5mA
- Output Configuration
- Positive
- Operating Voltage
- 15V
- Output Current
- 800mA
- Features
- Over Current Protection;Thermal shutdown
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.4 g
Overview
The LD1117 is a low drop voltage regulator capable of delivering 800 mA of output current, available even in adjustable version (V = 1.25 - 3.3 V) and in fixed versions, offered the following output voltages: 1.2 V, 1.8 V, 2.5 V, 2.85 V, 3.3 V and 5.0 V. The device is supplied in: SOT - 223, DPAK, SO - 8 and TO - 220. The SOT - 223 and DPAK surface mount package optimize the thermal characteristics even offering a relevant space saving effect. High efficiency is assured by NPN pass transistor. In fact in this unlike than PNP one, the quiescent current flows mostly into the load. Only a very common 10 µF minimum capacitor is needed for stability. Laser trimming allows the regulator to reach very tight output voltage tolerance, within ± 1 % at 25 °C. The adjustable LD1117 is pin to pin compatible with the other standard.
Key features
- Low dropout voltage (1 V for 2.85 V device at 800 mA)
- Fixed output voltage of: 1.2 V, (V_REF = 1.25 V), 1.8 V, 2.5 V, 2.85 V, 3.3 V, 5.0 V
- Regulation accuracy: ± 1 % at 25 °C and 2 %
- Available in ± 1 % (at 25 °C) and 2 %
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | LM1086T-3.3#C444381HGSEMI · TO-220 | HGSEMI | TO-220 | 1,340 | ₹38.27 · 1,340 in stock | View |
 | LD1117V33#C283467ST · TO-220 | ST | TO-220 | 5,891 | ₹65.18 · 5,891 in stock | View |
 | LD1086V33-DG#C500665ST · TO-220 | ST | TO-220 | 321 | ₹213.12 · 321 in stock | View |
 | LM1085IT-3.3/NOPB#C467006TI · TO-220-3 | TI | TO-220-3 | 22 | ₹448.26 · 22 in stock | View |
 | LM1117T-3.3/NOPB#C201726TI · TO-220 | TI | TO-220 | 398 | ₹249.88 · 398 in stock | View |
