TIDatasheet (PDF)
LM1117MPX-ADJ/NOPB
1.25V~13.8V Positive Adjustable SOT-223-4 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOT-223-4ROHS3 CompliantActive
800mA 15V linear regulator
- Manufacturer
- TI
- Manufacturer part #
- LM1117MPX-ADJ/NOPB
- Store part #
- C263277
- Package / case
- SOT-223-4
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
31,635 in stock
#C263277
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹41.99 | ₹209.95 |
| 50+ | ₹32.89 | ₹1,644.50 |
| 150+ | ₹27.43 | ₹4,114.50 |
| 500+ | ₹22.56 | ₹11,280.00 |
| 2,000+ | ₹20.39 | ₹40,780.00 |
| 4,000+ | ₹19.09 | ₹76,360.00 |
5 × ₹41.99
₹209.95
excl. GST
₹247.74 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
LM1117MPX-ADJ/NOPB
₹209.95 for 5 + GST
Specifications
- Output Voltage
- 1.25V~13.8V
- Number of Outputs
- 1
- Operating Temperature
- 0℃~+125℃@(Tj)
- Supply Current (Iq)
- 5mA
- Output Configuration
- Positive
- Operating Voltage
- 15V
- Output Current
- 800mA
- Features
- Over Current Protection;Thermal shutdown
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.293 g
Overview
The LM1117 is a low dropout voltage regulator with a dropout of 1.2 V at 800 mA of load current. The LM1117 is available in an adjustable version, which can set the output voltage from 1.25 to 13.8 V with only two external resistors. In addition, it is available in five fixed voltages, 1.8 V, 2.5 V, 3.3 V, and 5 V. The LM1117 offers current limiting and thermal shutdown. Its circuit includes a Zener trimmed bandgap reference to assure output voltage accuracy to within ±1%. A minimum of 10 μF tantalum capacitor is required at the output to improve the transient response and stability.
Applications
- Post Regulator for Switching DC–DC Converter
- High Efficiency Linear Regulators
- Battery Chargers
- Portable Instrumentation
- Active SCSI Termination Regulator
Key features
- Available in 1.8 V, 2.5 V, 3.3 V, 5 V, and Adjustable Versions
- Space-Saving SOT-223 and WSON Packages
- Current Limiting and Thermal Protection
- Output Current 800 mA
- Line Regulation 0.2% (Maximum)
- Load Regulation 0.4% (Maximum)
- Temperature Range: LM1117: 0°C to 125°C; LM1117I: -40°C to 125°C
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | LM1117IMPX-ADJ/NOPB#C19228TI · SOT-223-4 | TI | SOT-223-4 | 4,297 | ₹57.46 · 4,297 in stock | View |
 | LM1117IMP-ADJ/NOPB#C350541TI · SOT-223-4 | TI | SOT-223-4 | 780 | ₹62.70 · 780 in stock | View |
 | LM1117MPX-ADJNOPB#C2902259onsemi · SOT-223 | onsemi | SOT-223 | 801 | ₹96.92 · 801 in stock | View |
 | LM1117MP-ADJ/NOPB#C352831TI · SOT-223 | TI | SOT-223 | 326 | ₹59.81 · 326 in stock | View |
 | AMS1117-ADJ#C2992572GUOXIN JIAPIN SEMICONDUCTOR · SOT-223-3 | GUOXIN JIAPIN SEMICONDUCTOR | SOT-223-3 | 360 | ₹4.88 · 360 in stock | View |
