HGSEMIDatasheet (PDF)
LM2903N
1mV 100nA 2 DIP-8 Linear Comparators
DIP-8RoHSActive
- Manufacturer
- HGSEMI
- Manufacturer part #
- LM2903N
- Store part #
- C52121521
- Package / case
- DIP-8
- Category
- Linear Comparators
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
16,035 in stock
#C52121521
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹13.67 | ₹68.35 |
| 50+ | ₹10.86 | ₹543.00 |
| 150+ | ₹9.46 | ₹1,419.00 |
| 500+ | ₹8.40 | ₹4,200.00 |
| 2,000+ | ₹7.55 | ₹15,100.00 |
| 4,000+ | ₹7.14 | ₹28,560.00 |
5 × ₹13.67
₹68.35
excl. GST
₹80.65 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 50 per tube
LM2903N
₹68.35 for 5 + GST
Specifications
- Dual Supply
- ±16V
- Output Type
- Open Drain
- Vos - Input Offset Voltage
- 1mV
- Ib - Input Bias Current
- 100nA
- Quiescent Current
- 600uA
- Number of Channels
- 2
- Input Offset Current(Ios)
- 5nA
- Operating Temperature
- -40℃~+85℃
- Single Supply
- 2V~32V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.893 g
Overview
LM2903 is a dual voltage comparator with open-drain outputs, operable from single or dual supplies. It features excellent temperature stability and output short-circuit protection. It can be powered directly from a standard 5V supply in digital systems without requiring an additional power source.
Applications
- Voltage discriminator circuits
- Voltage conversion circuits
- Other application areas
Key features
- Single supply voltage range: 2V~32V
- Low output saturation voltage: typical 0.1V @ IOL = 4mA
- Low power consumption: typical 0.6mA @ VCC = 5V
- Low input offset voltage: typical ±1mV
- Dual supply voltage range: ±16V
- Differential input voltage range: ±VCC
- Open-drain output
- Package options: DIP-8, SOP-8, MSOP-8, DFN-8
