HGSEMI

LM4558M/TR

2 5mV 50nA 80dB 500uA 1.2MHz SOP-8 Instrumentation, Op Amps, Buffer Amps

SOP-8RoHSActive

Dual low-power differential operational amplifier

Manufacturer: HGSEMI
Manufacturer part #: LM4558M/TR
Store part #: C5116329
Package / case: SOP-8
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,725 in stock

#C5116329

Stock & price checked 31 h ago

Quantity	Unit price	Pack price
5+	₹11.38	₹56.90
50+	₹9.04	₹452.00
150+	₹7.87	₹1,180.50
500+	₹7.00	₹3,500.00
2,500+	₹6.09	₹15,225.00
5,000+	₹5.73	₹28,650.00

Quantity (min 5, multiples of 5)

5 × ₹11.38

₹56.90

excl. GST

₹67.14 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

LM4558M/TR

₹56.90 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

output type: Differential
Number of Channels: 2
Vos - Input Offset Voltage: 5mV
Input Offset Current(Ios): 10nA
Operating Temperature: 0℃~+70℃
Ib - Input Bias Current: 50nA
Common Mode Rejection Ratio(CMRR): 80dB
Power Supply Rejection Ratio (PSRR): 90dB
Maximum Power Supply Range (Vdd-Vss): 30V
Quiescent Current: 500uA
Gain Bandwidth Product: 1.2MHz
Features: Built-in compensation;Current limiting / short-circuit protection
Dual Supply: -15V~15V
Single Supply: 3V~30V

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.23 g
