TIDatasheet (PDF)
LP2966IMM-1833/NOPB
Positive Fixed VSSOP-8 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
VSSOP-8ROHS3 CompliantActive
150mA, dual-channel adjustable low-dropout regulator with power-good indication
- Manufacturer
- TI
- Manufacturer part #
- LP2966IMM-1833/NOPB
- Store part #
- C2872697
- Package / case
- VSSOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C2872697
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹373.46 | ₹373.46 |
| 10+ | ₹363.81 | ₹3,638.10 |
| 30+ | ₹357.38 | ₹10,721.40 |
| 100+ | ₹351.16 | ₹35,116.00 |
1 × ₹373.46
₹373.46
excl. GST
₹440.68 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
LP2966IMM-1833/NOPB
₹373.46 for 1 + GST
Specifications
- Output Voltage
- 1.8V;3.3V
- Number of Outputs
- 2
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 300uA
- Output Configuration
- Positive
- Operating Voltage
- 7V
- Output Current
- 150mA
- Output Type
- Fixed
- Features
- Enable control;Operating status indication;Over Current Protection;Short Circuit Protection;Thermal shutdown
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.39 g
Overview
The LP2966 dual ultra low-dropout (LDO) regulator operates from a +2.70V to +7.0V input supply. Each output delivers 150mA over full temperature range. The IC operates with extremely low drop-out voltage and quiescent current, which makes it very suitable for battery powered and portable applications. Each LDO in the LP2966 has independent shutdown capability. The LP2966 provides low noise performance with low ground pin current in an extremely small VSSOP - 8 package. A wide range of preset voltage options are available for each output. In all, 256 voltage combinations are possible.
Applications
- Cellular and Wireless Applications
- Palmtop/Laptop Computer
- GPS Systems
- Flat Panel Displays
- Post Regulators
- USB Applications
- Hand Held Equipment and Multimeters
- Wireless Data Terminals
- Other Battery Powered Applications
Key features
- Ultra Low Drop - Out Voltage
- Low Ground Pin Current
- < 1μA Quiescent Current in Shutdown Mode
- Independent Shutdown of Each LDO Regulator
- Output Voltage Accuracy ±1%
- Ensured 150mA Output Current at Each Output
- Low Output Noise
- Error Flags Indicate Status of Each Output
- Available in VSSOP - 8 Surface Mount Package
- Low Output Capacitor Requirements (1µF)
- Operates with Low ESR Ceramic Capacitors in Most Applications
- Over Temperature/Over Current Protection
- -40°C to ±125°C Junction Temperature Range
