LOWPOWERDatasheet (PDF)
LP3992-28B5F
Linear Voltage Regulator IC Positive Fixed 1 Output 300mA SOT-23-5
SOT-23-5RoHSActive
IC REG LINEAR 2.8V 300mA SOT-23-5
- Manufacturer
- LOWPOWER
- Manufacturer part #
- LP3992-28B5F
- Store part #
- C387684
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,960 in stock
#C387684
Stock & price checked 31 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.58 | ₹65.80 |
| 100+ | ₹5.20 | ₹520.00 |
| 300+ | ₹4.51 | ₹1,353.00 |
| 3,000+ | ₹4.00 | ₹12,000.00 |
| 6,000+ | ₹3.59 | ₹21,540.00 |
| 9,000+ | ₹3.37 | ₹30,330.00 |
10 × ₹6.58
₹65.80
excl. GST
₹77.64 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
LP3992-28B5F
₹65.80 for 10 + GST
Specifications
- Output Voltage
- 2.8V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 75uA
- Output Configuration
- Positive
- Output Current
- 300mA
- Operating Voltage
- 5.5V
- Features
- Enable control;Over Current Protection;Thermal shutdown;Output discharge
- Output Type
- Fixed
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.024 g
Overview
The LP3992 is designed for portable RF and wireless applications with demanding performance and space requirements. The LP3992 performance is optimized for battery-powered systems to deliver ultra low noise and low quiescent current. The LP3992 also works with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications, critical in hand-held wireless devices. The LP3992 consumes less than 0.01 μA in shutdown mode and has fast turn-on time less than 50 μs. The other features include ultra low dropout voltage, high output accuracy, current limiting protection, and high ripple rejection ratio. It is available in the 5-lead of SOT23-5 and TSOT23-5 packages.
Applications
- Portable Media Players/MP3 players
- Cellular and Smart mobile phone
- LCD
- DSC
- Sensor
- Wireless Card
Key features
- Ultra-Low-Noise for RF Application
- 2.5V - 5.5V Input Voltage Range
- Low Dropout: 220mV @ 300mA
- 1.2V, 1.5V, 1.8V, 2.5V, 2.8V, 3.0V, 3.3V, 3.6V and 5V Fixed
- 300mA Output Current
- High PSSR: -76dB at 1KHz
- <0.01μA Standby Current When Shutdown
- Available in SOT23-5 and TSOT23-5 Package
- TTL-Logic-Controlled Shutdown Input
- Ultra-Fast Response in Line/Load transient
- Current Limiting and Thermal Shutdown Protection
- Quick start-up (typically 50μS)
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | LP3982S-28B5F#C47345735LOWPOWER · SOT-23-5 | LOWPOWER | SOT-23-5 | 1,500 | ₹8.36 · 1,500 in stock | View |
 | LP3982H-28B5F#C47345749LOWPOWER · SOT-23-5 | LOWPOWER | SOT-23-5 | 3,000 | ₹7.45 · 3,000 in stock | View |
 | LP3980-28B5F#C517192LOWPOWER · SOT-23-5 | LOWPOWER | SOT-23-5 | 1,970 | ₹8.89 · 1,970 in stock | View |
 | LP3981-28B5F#C517238LOWPOWER · SOT-23-5 | LOWPOWER | SOT-23-5 | 360 | ₹7.89 · 360 in stock | View |
 | LP3984-28B5F#C517244LOWPOWER · SOT-23-5 | LOWPOWER | SOT-23-5 | 5,100 | ₹5.45 · 5,100 in stock | View |
