LP590728QDQNRQ1
Linear Voltage Regulator IC Positive Fixed 1 Output 250mA X2-SON-4-EP(1x1)
X2-SON-4-EP(1x1)ROHS3 CompliantActive
Low IQ, enabled functionality automotive-grade 250mA, low-noise, high PSRR, ultra-low dropout regulator
- Manufacturer
- TI
- Manufacturer part #
- LP590728QDQNRQ1
- Store part #
- C2873191
- Package / case
- X2-SON-4-EP(1x1)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C2873191
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹164.54 | ₹164.54 |
| 10+ | ₹146.52 | ₹1,465.20 |
| 30+ | ₹129.57 | ₹3,887.10 |
| 100+ | ₹116.93 | ₹11,693.00 |
| 500+ | ₹111.78 | ₹55,890.00 |
| 1,000+ | ₹109.20 | ₹1,09,200.00 |
1 × ₹164.54
₹164.54
excl. GST
₹194.16 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
LP590728QDQNRQ1
₹164.54 for 1 + GST
Specifications
- Output Voltage
- 2.8V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 25uA
- Output Configuration
- Positive
- Operating Voltage
- 5.5V
- Output Current
- 250mA
- Output Type
- Fixed
- Features
- Enable control;Output discharge;Thermal shutdown;Short Circuit Protection
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.067 g
Overview
The LP5907-Q1 is a low-noise LDO capable of delivering 250mA output current. Designed to meet RF and analog circuit requirements, it offers low noise, high PSRR, low quiescent current, and low line/load transient response. Using innovative design techniques, the LP5907-Q1 achieves excellent noise performance without a noise bypass capacitor and supports remote placement of the output capacitor. The device operates with 1μF input and 1μF output ceramic capacitors, eliminating the need for a separate noise bypass capacitor. Fixed output voltage ranges from 1.2V to 4.5V in 25mV steps.
Applications
- ADAS cameras and radar
- Automotive infotainment systems
- In-vehicle communication and navigation systems
Key features
- Automotive-qualified per AEC-Q100 with the following results:
- Device temperature grade 1: ambient operating temperature range –40°C to 125°C
- Device HBM ESD classification level 2
- Device CDM ESD classification level C6
- Stable performance with 1μF ceramic input and output capacitors
- Input voltage range: 2.2V to 5.5V
- Output voltage range: 1.2V to 4.5V
- Remote output capacitor placement support
- Thermal overload and short-circuit protection
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | UM1540DB-28#C7542866Union Semiconductor · DFN4-EP(1.0x1.0) | Union Semiconductor | DFN4-EP(1.0x1.0) | 20 | ₹13.39 · 20 in stock | View |
 | LP5907SNX-2.8/NOPB#C882783TI · X2-SON-4-EP(1x1) | TI | X2-SON-4-EP(1x1) | 5,225 | ₹27.12 · 5,225 in stock | View |
 | SK6013SD4-28#C47325472Suntek · DFN-4-EP(1x1) | Suntek | DFN-4-EP(1x1) | 180 | ₹13.59 · 180 in stock | View |
 | PJ9350L28DE#C22470322PJSEMI · DFN-4L(1x1) | PJSEMI | DFN-4L(1x1) | 445 | ₹10.12 · 445 in stock | View |
 | AP7353-28FS4-7#C3744954DIODES · X2-DFN1010-4 | DIODES | X2-DFN1010-4 | 80 | ₹22.16 · 80 in stock | View |
