LP5907UVX-3.3/NOPB

3.3V Positive Fixed DSBGA-4 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS

DSBGA-4ROHS CompliantActive

250mA, low noise, high PSRR, ultra-low dropout regulator with low IQ and enable functionality

Manufacturer: TI
Manufacturer part #: LP5907UVX-3.3/NOPB
Store part #: C165149
Package / case: DSBGA-4
Category: Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

4,915 in stock

#C165149

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹23.21	₹116.05
50+	₹18.69	₹934.50
150+	₹16.75	₹2,512.50
500+	₹13.46	₹6,730.00
3,000+	₹12.39	₹37,170.00
6,000+	₹11.75	₹70,500.00

Quantity (min 5, multiples of 5)

5 × ₹23.21

₹116.05

excl. GST

₹136.94 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

LP5907UVX-3.3/NOPB

₹116.05 for 5 + GST

Specifications

Output Voltage: 3.3V
Number of Outputs: 1
Operating Temperature: -40℃~+125℃@(Tj)
Supply Current (Iq): 12uA
Output Configuration: Positive
Operating Voltage: 5.5V
Output Current: 250mA
Features: Enable control;Output discharge;Thermal shutdown;Short Circuit Protection;Input under-voltage protection
Output Type: Fixed

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.066 g

Overview

The LP5907 is a low-noise LDO that can supply up to 250 mA output current. Designed to meet the requirements of RF and analog circuits, the LP5907 device provides low noise, high PSRR, low quiescent current, and low line or load transient response figures. Using new innovative design techniques, the LP5907 offers class-leading noise performance without a noise bypass capacitor and the ability for remote output capacitor placement.

Applications

Mobile Phones, Tablets
Digital Cameras and Audio Devices
Portable and Battery-Powered Equipment
Portable Medical Equipment
Smart Meters and Field Transmitters
RF, PLL, VCO, and Clock Power Supplies
IP Cameras
Drones

Key features

Input Voltage Range: 2.2 V to 5.5 V
Output Voltage Range: 1.2 V to 4.5 V
Stable With 1 μF Ceramic Input and Output Capacitors
No Noise Bypass Capacitor Required
Remote Output Capacitor Placement
Thermal-Overload and Short-Circuit Protection
-40°C to 125°C Operating Junction Temperature
Low Output Voltage Noise: <6.5 μV RMS
PSRR: 82 dB at 1 kHz
Output Voltage Tolerance: ±2%
Very Low IQ (Enabled): 12 μA
Low Dropout: 120 mV (typical)
Create a Custom Design Using the LP5907 With the WEBENCH Power Designer
