LP8340ILDX-ADJ/NOPB
1.231V~1.288V Positive Adjustable WSON-6-EP(2.9x3.3) Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
WSON-6-EP(2.9x3.3)ROHS3 CompliantActive
1A, 10V, low IQ, low-dropout regulator
- Manufacturer
- TI
- Manufacturer part #
- LP8340ILDX-ADJ/NOPB
- Store part #
- C2866898
- Package / case
- WSON-6-EP(2.9x3.3)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C2866898
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹252.34 | ₹252.34 |
| 10+ | ₹245.91 | ₹2,459.10 |
| 30+ | ₹241.62 | ₹7,248.60 |
| 100+ | ₹237.33 | ₹23,733.00 |
1 × ₹252.34
₹252.34
excl. GST
₹297.76 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 4,500 per reel
LP8340ILDX-ADJ/NOPB
₹252.34 for 1 + GST
Specifications
- Output Voltage
- 1.231V~1.288V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Ta)
- Supply Current (Iq)
- 19uA
- Output Configuration
- Positive
- Operating Voltage
- 10V
- Output Current
- 1A
- Output Type
- Adjustable
- Features
- Over Current Protection;Thermal shutdown
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.78 g
Overview
The LP8340 low-dropout CMOS linear regulator is available in 5V, 3.3V, 2.5V, 1.8V and adjustable output versions. Packaged in the 6ld WSON package and 3ld PFM. The LP8340 can deliver up to 1.0A output current. Typical dropout voltage is 420mV at 1.0A for the 5.0V version, 540mV at 1.0A for the 3.3V version, 670mV at 1.0A for the 2.5V version and 680mV at 800mA for the 1.8V version. The LP8340 includes a zener trimmed bandgap voltage reference, foldback current limiting and thermal overload limiting. The LP8340 features a PMOS output transistor which unlike PNP type low dropout regulators requires no base drive current. This allows the device ground current to remain less than 50μA over operating temperature, supply voltage and irrespective of the load current.
Applications
- Hard Disk Drives
- Notebook Computers
- Battery Powered Electronics
- Portable Instrumentation
Key features
- ±1.5% Typical VOUT Tolerance
- 420mV Typical Dropout @ 1.0A (VO = 5V)
- Wide Operating Range 2.7V to 10V
- Internal 1.0A PMOS Output Transistor
- 19μA Typical Quiescent Current
- Thermal Overload Limiting
- Foldback Current Limiting
- Zener Trimmed Bandgap Reference
- Space Saving WSON package
- Temperature Range: LP8340C 0°C to 125°C, LP8340I -40°C to 125°C
