LT1963AES8#TRPBF
1.21V~20V Positive Adjustable SO-8 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SO-8ROHS3 CompliantActive
1.5A, Low Noise, Fast Transient Response LDO Regulators
- Manufacturer
- ADI
- Manufacturer part #
- LT1963AES8#TRPBF
- Store part #
- C48849
- Package / case
- SO-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
52 in stock
#C48849
Stock & price checked 33 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹1,267.51 | ₹1,267.51 |
| 10+ | ₹1,097.42 | ₹10,974.20 |
| 30+ | ₹993.65 | ₹29,809.50 |
| 100+ | ₹826.60 | ₹82,660.00 |
1 × ₹1,267.51
₹1,267.51
excl. GST
₹1,495.66 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
LT1963AES8#TRPBF
₹1,267.51 for 1 + GST
Specifications
- Output Voltage
- 1.21V~20V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 1mA
- Output Configuration
- Positive
- Operating Voltage
- 20V
- Output Current
- 1.5A
- Features
- Reverse polarity voltage protection;Reverse-polarity current protection;Over Current Protection;Thermal shutdown
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.17 g
