MAXIMDatasheet (PDF)
MAX13487EESA+
4.75V~5.25V Transceiver 500Kbps 128 SOIC-8 Drivers, Receivers, Transceivers RoHS
SOIC-8ROHS3 CompliantActive
Half-Duplex RS-485-/RS-422- Compatible Transceiver with AutoDirection Control
- Manufacturer
- MAXIM
- Manufacturer part #
- MAX13487EESA+
- Store part #
- C143342
- Package / case
- SOIC-8
- Category
- Drivers, Receivers, Transceivers
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,942 in stock
#C143342
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹149.68 | ₹149.68 |
| 10+ | ₹131.09 | ₹1,310.90 |
| 30+ | ₹113.56 | ₹3,406.80 |
| 100+ | ₹100.57 | ₹10,057.00 |
| 500+ | ₹95.15 | ₹47,575.00 |
| 1,000+ | ₹92.44 | ₹92,440.00 |
1 × ₹149.68
₹149.68
excl. GST
₹176.62 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 100 per tube
MAX13487EESA+
₹149.68 for 1 + GST
Specifications
- Voltage - Supply
- 4.75V~5.25V
- Type
- Transceiver
- Data Rate
- 500Kbps
- Number of Nodes
- 128
- Operating Temperature
- -40℃~+85℃
- ESD Protect
- ±15kV
- Communication Mode
- Half-Duplex
- Number of Drivers
- 1
- Features
- Hot-swap protection;Automatic direction control;Low-power mode
- Number of Receivers
- 1
- Quiescent Supply Current
- 4.5mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 100 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.219 g
Overview
The MAX13487E/MAX13488E +5V, half-duplex, ±15KV ESD-protected RS-485/RS-422-compatible transceivers feature one driver and one receiver. The MAX13487E/ MAX13488E include a hot-swap capability to eliminate false transitions on the bus during power-up or live insertion. The MAX13487E/MAX13488E feature Maxim’s proprietary AutoDirection control. This architecture makes the devices ideal for applications, such as isolated RS-485 ports, where the driver input is used in conjunction with the driver-enable signal to drive the differential bus. The MAX13487E features reduced slew-rate drivers that minimize EMI and reduce reflections caused by improperly terminated cables, allowing error-free transmission up to 500kbps. The MAX13488E driver slew rate is not limited, allowing transmit speeds up to 16Mbps. The MAX13487E/MAX13488E feature a 1/4 -unit load receiver input impedance, allowing up to 128 transceivers on the bus. These devices are intended for halfduplex communications. All driver outputs are protected to ±15KV ESD using the Human Body Model. The MAX13487E/MAX13488E are available in an 8-pin SO package. The devices operate over the extended - 40°C to +85°C temperature range.
Applications
- Isolated RS-485 Interfaces
- Utility Meters
- Industrial Controls
- Industrial Motor Drives
- Automated HVAC Systems
Key features
- AutoDirection Saves Space and BOM Cost
- AutoDirection Enables Driver Automatically on Transmission, Eliminating an Opto or Other Discrete Means of Isolation
- 8-Pin SO Package
- Robust Protection Features for Telecom, Industrial, and Isolated Applications
- Hot-Swap Capability to Eliminate False Transitions on the Bus During Power-Up or Live Insertion
- Extended ESD Protection for RS-485 I/O Pins (±15kV Human Body Model)
- Options Optimize Designs for Speed or Errorless Data Transmission
- Enhanced Slew-Rate Limiting Facilitates ErrorFree Data Transmission (MAX13487E)
- High-Speed Version (MAX13488E) Allows for Transmission Speeds Up to 16Mbps
- 1/4-Unit Load, Allowing Up to 128 Transceivers on the Bus
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MAX13487EESA+T#C18347MAXIM · SOIC-8 | MAXIM | SOIC-8 | 38,260 | ₹124.40 · 38,260 in stock | View |
 | MAX13488EESA+#C143343MAXIM · SO-8 | MAXIM | SO-8 | 221 | ₹375.87 · 221 in stock | View |
 | MAX13488EESA+T#C156258MAXIM · SOIC-8 | MAXIM | SOIC-8 | 21,764 | ₹185.19 · 21,764 in stock | View |
 | MAX1487EESA+T#C118521MAXIM · SOIC-8 | MAXIM | SOIC-8 | 707 | ₹264.27 · 707 in stock | View |
 | MAX1487ESA+T#C40095MAXIM · SOIC-8 | MAXIM | SOIC-8 | 1,125 | ₹249.33 · 1,125 in stock | View |
