onsemi

MC14069UBDTR2G

3V~18V 55ns@15V,50pF 1uA 6 TSSOP-14 Gates and Inverters RoHS

TSSOP-14ROHS3 CompliantActive

Hex Inverter

Manufacturer: onsemi
Manufacturer part #: MC14069UBDTR2G
Store part #: C903929
Package / case: TSSOP-14
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

3,095 in stock

#C903929

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
5+	₹42.98	₹214.90
50+	₹33.46	₹1,673.00
150+	₹29.37	₹4,405.50
500+	₹24.26	₹12,130.00
2,500+	₹22.00	₹55,000.00
5,000+	₹20.64	₹1,03,200.00

Quantity (min 5, multiples of 5)

5 × ₹42.98

₹214.90

excl. GST

₹253.58 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

MC14069UBDTR2G

₹214.90 for 5 + GST

Specifications

Logic Family: 4000B
Voltage - Supply: 3V~18V
Output Logic Level - Low: 50mV
Propagation Delay: 55ns@15V,50pF
Operating Temperature: -55℃~+125℃
Input Logic Level - Low: 1V~2.5V
Input Logic Level - High: 4V~12.5V
Output Logic Level - High: 4.95V
Quiescent Current(Iq): 1uA
Current - Output High(IOH): 8.8mA
Number of Channels: 6
Current - Output Low(IOL): 8.8mA

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.197 g

Overview

The MC14069UB hex inverter is constructed with MOS P−channel and N. −channel enhancement mode devices in a single monolithic structure. These inverters find primary use where low power dissipation and/or high noise immunity is desired. Each of the six inverters is a single stage to minimize propagation delays.

Key features

Supply Voltage Range = 3.0 Vdc to 18 Vdc
Capable of Driving Two Low−Power TTL Loads or One Low−Power Schottky TTL Load Over the Rated Temperature Range
Triple Diode Protection on All Inputs
Pin−for−Pin Replacement for CD4069UB
Meets JEDEC UB Specifications
NLV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q100 Qualified and PPAP Capable
These Devices are Pb−Free and are RoHS Compliant
