MC79L05ACDR
5V Negative Fixed SOIC-8 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOIC-8ROHS3 CompliantActive
100mA Negative Voltage Linear Regulator
- Manufacturer
- TI
- Manufacturer part #
- MC79L05ACDR
- Store part #
- C7374
- Package / case
- SOIC-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5,415 in stock
#C7374
Stock & price checked 31 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹30.98 | ₹154.90 |
| 50+ | ₹24.32 | ₹1,216.00 |
| 150+ | ₹21.08 | ₹3,162.00 |
| 500+ | ₹18.16 | ₹9,080.00 |
| 2,500+ | ₹17.37 | ₹43,425.00 |
| 5,000+ | ₹16.89 | ₹84,450.00 |
5 × ₹30.98
₹154.90
excl. GST
₹182.78 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
MC79L05ACDR
₹154.90 for 5 + GST
Specifications
- Output Voltage
- 5V
- Number of Outputs
- 1
- Operating Temperature
- 0℃~+125℃@(Tj)
- Output Configuration
- Negative
- Operating Voltage
- 20V
- Output Current
- 100mA
- Features
- Thermal shutdown;Short Circuit Protection;Over Current Protection;Enable control
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.173 g
Overview
This series of fixed negative-voltage integrated-circuit voltage regulators is designed for a wide range of applications. These include on-card regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, they can be used to control series pass elements to make high-current voltage-regulator circuits. One of these regulators can deliver up to 100 mA of output current. The internal current-limiting and thermal-shutdown features essentially make the regulators immune to overload. When used as a replacement for a Zener-diode and resistor combination, these devices can provide an effective improvement in output impedance of two orders of magnitude, with lower bias current.
Key features
- Output Current Up To 100 mA
- No External Components Required
- Internal Thermal-Overload Protection
- Internal Short-Circuit Current Limiting
- Direct Replacement for Industry-Standard MC79L00 Series
- Available in 5% or 10% Selections
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MC79L05ACDR2G#C154823onsemi · SOIC-8 | onsemi | SOIC-8 | 5,385 | ₹20.68 · 5,385 in stock | View |
 | L79L05ACD13TR#C2802525ST · SO-8 | ST | SO-8 | 8,695 | ₹27.02 · 8,695 in stock | View |
 | MC79L05ABDR2G#C232661onsemi · SOIC-8 | onsemi | SOIC-8 | 4,155 | ₹30.15 · 4,155 in stock | View |
 | HT79L05ARZ#C5274692HTCSEMI · SOP-8 | HTCSEMI | SOP-8 | 205 | ₹31.09 · 205 in stock | View |
 | LM79L05ACMX/NOPB#C7555TI · SOIC-8-150mil | TI | SOIC-8-150mil | 4,945 | ₹42.84 · 4,945 in stock | View |
