UMW
XC6206P332MRLinear Voltage Regulator IC Positive Fixed 1 Output 250mA SOT-23
From
₹2.53
18,64,100 in stock
MICRONEDatasheet (PDF)
ME6228A33M3G
Linear Voltage Regulator IC Positive Fixed 1 Output 150mA SOT-23-3
SOT-23-3ROHS CompliantActive
Linear voltage regulator with a 150mA load capacity, 0.8μA low power consumption, and 30V high voltage tolerance
- Manufacturer
- MICRONE
- Manufacturer part #
- ME6228A33M3G
- Store part #
- C487914
- Package / case
- SOT-23-3
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
12,390 in stock
#C487914
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹7.62 | ₹76.20 |
| 100+ | ₹5.94 | ₹594.00 |
| 300+ | ₹5.11 | ₹1,533.00 |
| 3,000+ | ₹4.48 | ₹13,440.00 |
| 6,000+ | ₹3.98 | ₹23,880.00 |
| 9,000+ | ₹3.73 | ₹33,570.00 |
10 × ₹7.62
₹76.20
excl. GST
₹89.92 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
ME6228A33M3G
₹76.20 for 10 + GST
Specifications
- Output Voltage
- 3.3V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+150℃@(Tj)
- Supply Current (Iq)
- 800nA
- Output Configuration
- Positive
- Operating Voltage
- 30V
- Output Current
- 150mA
- Features
- Short Circuit Protection
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.051 g
Overview
ME6228 is a low dropout, low quiescent current linear regulator fabricated using CMOS process, integrating a reference circuit, error amplifier, and feedback resistor network. The ME6228 supports an input voltage up to 30V and an output current up to 150mA. The internal feedback voltage sets a fixed output voltage, ranging from 1.5V to 12V.
Applications
- Battery-powered devices
- Audio/video equipment
- Communication equipment
Key features
- High input voltage: up to 30V
- Ultra-low quiescent current: 0.8uA (Typ)
- Output voltage range: 1.5~12V
- Output voltage accuracy:
- ±1% (VOUT = 1.8V, 3.3V, 3.6V, 4.0V, 5.0V)
- ±2% (other voltage values)
- Output current: IOUT = 150mA (VIN = 4.8V & VOUT = 3.3V)
- Short-circuit current: 18mA
- Low temperature coefficient
- Stable output with low-ESR ceramic capacitors
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | ME6239A33M3G#C151879MICRONE · SOT-23 | MICRONE | SOT-23 | 7,295 | ₹11.17 · 7,295 in stock | View |
