EATONDatasheet (PDF)
MSMA2512R0020FGM
2mΩ 3W ±50ppm/℃ ±1% 2512 Chip Resistor - Surface Mount RoHS
2512ROHS3 CompliantActive
RES 2mΩ ±1% 3W 2512
- Manufacturer
- EATON
- Manufacturer part #
- MSMA2512R0020FGM
- Store part #
- C6685125
- Package / case
- 2512
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
189 in stock
#C6685125
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹76.52 | ₹76.52 |
| 10+ | ₹61.35 | ₹613.50 |
| 30+ | ₹54.93 | ₹1,647.90 |
| 100+ | ₹46.81 | ₹4,681.00 |
| 500+ | ₹43.18 | ₹21,590.00 |
| 1,000+ | ₹41.04 | ₹41,040.00 |
1 × ₹76.52
₹76.52
excl. GST
₹90.29 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
MSMA2512R0020FGM
₹76.52 for 1 + GST
Specifications
- Resistance
- 2mΩ
- Power(Watts)
- 3W
- Temperature Coefficient
- ±50ppm/℃
- Tolerance
- ±1%
- Operating Temperature
- -55℃~+170℃
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.064 g
Overview
Applications
- Switching Mode Power Supply (SMPS)
- Voltage Regulation Modules
- Power Management
- Stepper Motor Drivers
Key features
- Low sensing resistance
- Package sizes from 0603 (1608 metric) to 2512 (6432 metric)
- High power dissipation
- AEC-Q200 compliant
- Moisture Sensitivity Level (MSL): 1
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | LR12FTDRR002#C316197Viking · 2512 | Viking | 2512 | 1,615 | ₹27.51 · 1,615 in stock | View |
 | CRE2512-FZ-R002E-3#C840614BOURNS · 2512 | BOURNS | 2512 | 1,260 | ₹52.39 · 1,260 in stock | View |
| TLR3APDTE2L00F50#C4026436KOA · 2512 | KOA | 2512 | 50 | ₹192.88 · 50 in stock | View | |
 | BVT-V-R002-1.0#C7223425Isabellenhuette · 2512 | Isabellenhuette | 2512 | 1,000 | ₹103.97 · 1,000 in stock | View |
 | BVT-I-R002-1.0#C2874129Isabellenhuette · 2512 | Isabellenhuette | 2512 | 4,689 | ₹111.24 · 4,689 in stock | View |
