MSKSEMI

MSTPS7A2028PDQNR

2.8V Positive Fixed DFN-4L(1x1) Voltage Regulators - Linear, Low Drop Out (LDO) Regulators

DFN-4L(1x1)RoHSActive

IC REG LINEAR 2.8V 300mA DFN-4L(1x1)

Manufacturer: MSKSEMI
Manufacturer part #: MSTPS7A2028PDQNR
Store part #: C49208541
Package / case: DFN-4L(1x1)
Category: Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,780 in stock

#C49208541

Stock & price checked 12 days ago

Quantity	Unit price	Pack price
5+	₹23.60	₹118.00
50+	₹20.64	₹1,032.00
150+	₹19.37	₹2,905.50
500+	₹17.78	₹8,890.00
2,500+	₹17.07	₹42,675.00
5,000+	₹16.64	₹83,200.00

Quantity (min 5, multiples of 5)

5 × ₹23.60

₹118.00

excl. GST

₹139.24 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 10,000 per reel

MSTPS7A2028PDQNR

₹118.00 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Output Voltage: 2.8V
Number of Outputs: 1
Operating Temperature: -40℃~+125℃
Supply Current (Iq): 800nA
Output Configuration: Positive
Operating Voltage: 5.5V
Output Current: 300mA
Output Type: Fixed
Features: Enable control;Over Current Protection;Output discharge;Thermal shutdown;Short Circuit Protection

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 10,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.007 g

Overview

MSTPS7A20xxPDQNR is a low-I0, low-dropout linear regulator with a 300mA drive current. The device features <0.1μA shutdown current and 0.8μA quiescent current under light-load conditions, delivering excellent power consumption performance for portable devices. It provides an output voltage range of 0.8~3.6V for a wide variety of applications, with integrated thermal shutdown and current-limiting protection.
