MX113H
SOT-23-6 Motor Drivers, Controllers RoHS
SOT-23-6ROHS CompliantActive
H-bridge driver circuit
- Manufacturer
- Mixic
- Manufacturer part #
- MX113H
- Store part #
- C2845122
- Package / case
- SOT-23-6
- Category
- Motor Drivers, Controllers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
15,255 in stock
#C2845122
Stock & price checked 22 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹18.80 | ₹94.00 |
| 50+ | ₹15.24 | ₹762.00 |
| 150+ | ₹13.47 | ₹2,020.50 |
| 500+ | ₹12.13 | ₹6,065.00 |
| 3,000+ | ₹9.02 | ₹27,060.00 |
| 6,000+ | ₹8.49 | ₹50,940.00 |
5 × ₹18.80
₹94.00
excl. GST
₹110.92 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MX113H
₹94.00 for 5 + GST
Specifications
- Drive Type
- Bipolar Driver
- Number of H-bridges
- 1
- Features
- Over temperature protection;Dead-time / shoot-through protection
- Technology
- Yes
- Operating Temperature
- -40℃~+85℃
- Output Current
- 1A
- Control Voltage
- 2V~8V
- RDS(on)
- 400mΩ
- Motor Drive Voltage(Vm)
- 2V~8V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.047 g
Overview
This product adopts an H-bridge circuit topology with high-reliability power transistor process, particularly suited for driving inductive loads such as coils and motors. The circuit integrates N-channel and P-channel power MOSFETs internally, with an operating voltage range of 2V to 8V. At 27°C with VCC = 6.5V, the maximum continuous output current reaches 1A and the maximum peak output current reaches 1.5A.
Applications
- IR-CUT driver
- Electric toys
- Stepper motor driver
Key features
- Low standby current (< 0.1uA)
- Low on-resistance MOSFET power switch designed with MOS process; 800mA power switch on-resistance 0.4Ω
- Integrated freewheeling diode — no external freewheeling diode required
- Ultra-compact package: SOT23-6, overall dimensions 2.92mm × 2.8mm (including leads)
- Low input current — integrated ~15K pull-down resistor to GND
- Built-in thermal shutdown (TSD) with hysteresis
- ESD rating: 3KV (HBM)
