MX15EDGKAM-3.81-13P-GN01-Cu-Y-A MAX
MAX

MX15EDGKAM-3.81-13P-GN01-Cu-Y-A

13 Position Male Plug 3.81mm Pitch

P=3.81mmROHS CompliantActive

TERM BLOCK PLUG 13POS 3.81mm

Manufacturer
MAX
Manufacturer part #
MX15EDGKAM-3.81-13P-GN01-Cu-Y-A
Store part #
C20423390
Package / case
P=3.81mm
Category
Headers, Plugs and Sockets
Packaging
Bag-packed
Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

170 in stock

#C20423390

Stock & price checked 8 days ago

QuantityUnit pricePack price
1+₹192.93₹192.93
10+₹160.53₹1,605.30
30+₹142.71₹4,281.30
90+₹122.55₹11,029.50
540+₹113.53₹61,306.20
1,080+₹109.45₹1,18,206.00

1 × ₹192.93

₹192.93

excl. GST

₹227.66 incl. 18% GST

Need volume or a scheduled delivery? Request a quote
  • Dispatch in 7–10 working days
  • GST invoice with every order
  • Standard pack: 90 per bag

MX15EDGKAM-3.81-13P-GN01-Cu-Y-A

₹192.93 for 1 + GST

Specifications

Wire Gauge - AWG
16~28
Number of Positions or Pins
1x13P
Number of Pins
13P
Operating Temperature
-40℃~+105℃
Number of PINs Per Row
13
Number of Rows
1
Current Rating
8A
Outlet Direction (Vertical Basis)
Horizontal Termination
Connection Type
Screw Connection (M2)
Voltage Rating
300V
Pitch
3.81mm
Connector Type
Male Plug
Color
Green
Mounting Type
Free-hanging
Termination Style
Screw

Packaging & compliance

RoHS
ROHS Compliant
Lifecycle
Active
Moisture sensitivity
MSL 2 (1 year)
Packaging
Bag-packed
Standard pack
90 / Bag
Sold per
Piece
Minimum order
1
Unit weight
11.3 g
