MXIC
MX25L3206EM2I-12G
FLASH - NOR Memory IC 32Mbit SPI 86MHz SOP-8-200mil
SOP-8-200milRoHSActive
IC FLASH 32Mbit SPI SOP-8-200mil
Datasheet (PDF)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,361 in stock
#C415880
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹371.19 | ₹371.19 |
| 10+ | ₹323.28 | ₹3,232.80 |
| 30+ | ₹293.36 | ₹8,800.80 |
| 100+ | ₹262.56 | ₹26,256.00 |
| 500+ | ₹248.70 | ₹1,24,350.00 |
| 1,000+ | ₹242.62 | ₹2,42,620.00 |
1 × ₹371.19
₹371.19
excl. GST
₹438.00 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
MX25L3206EM2I-12G
₹371.19 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Features
- Write enable latch;Power-on reset;Hardware write protection;Software write protection;Absolute write protection
- Memory Size
- 32Mbit
- Voltage - Supply
- 2.7V~3.6V
- Program / Erase Cycles
- 100,000 cycles
- Clock Frequency
- 86MHz
- Data Retention - TDR (Year)
- 20 Years
- Block Erase Time(tBE)
- 400ms@(64KB)
- Page Programming Time (Tpp)
- 600us
- Standby Supply Current
- 15uA
- Interface
- SPI
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- 3A991B1A
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.345 g
Overview
Key features
- Single Power Supply Operation - 2.7 to 3.6 volt for read, erase, and program operations
- Serial Peripheral Interface compatible -- Mode 0 and Mode 3
- 33,554,432 x 1 bit structure or 16,777,216x2 bits (Dual Output mode) structure
- 1024 Equal Sectors with 4K byte each - Any Sector can be erased individually
- 64 Equal Blocks with 64K byte each - Any Block can be erased individually
- Program Capability - Byte base - Page base (256 bytes)
- Latch-up protected to 100mA from -1V to Vcc +1V
- High Performance - Fast access time: 86MHz serial clock - Serial clock of Dual Output mode : 80MHz - Fast program time: 0.6ms(typ.) and 3ms(max.)/page - Byte program time: 9us (typical) - Fast erase time: 40ms(typ.) /sector ; 0.4s(typ.) /block
- Low Power Consumption - Low active read current: 25mA(max.) at 86MHz - Low active programming current: 15mA (typ.) - Low active sector erase current: 9mA (typ.) - Standby current: 15uA (max.) - Deep power-down mode 2uA (typical)
- Typical 100,000 erase/program cycles
- 20 years of data retention
- Input Data Format - 1-byte Command code
- Advanced Security Features - Block lock protection The BP3~BP0 status bit defines the size of the area to be software protection against program and erase instructions
- Additional 512 bits secured OTP for unique identifier
- Auto Erase and Auto Program Algorithm - Automatically erases and verifies data at selected sector - Automatically programs and verifies data at selected page by an internal algor
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | GD25Q32CSIGR#C318845GigaDevice Semicon Beijing · SOIC-8-208mil | GigaDevice Semicon Beijing | SOIC-8-208mil | 12,191 | ₹172.28 · 12,191 in stock | View |
 | 25Q32-TD#C47108718TDSEMIC · SOP-8-208mil | TDSEMIC | SOP-8-208mil | 482 | ₹141.90 · 482 in stock | View |
 | W25Q32DR-TD#C49211309TDSEMIC · SOP-8-208mil | TDSEMIC | SOP-8-208mil | 249 | ₹155.81 · 249 in stock | View |
 | EN25Q32C-104HIP2B#C492204ESMT(Elite Semicon Memory Tech) · SOP-8-208mil | ESMT(Elite Semicon Memory Tech) | SOP-8-208mil | 11 | ₹65.41 · 11 in stock | View |
 | BY25Q32CSSIG(T)#C50172600BOYAMICRO · SOP-8-208mil | BOYAMICRO | SOP-8-208mil | 33 | ₹42.60 · 33 in stock | View |
