onsemiDatasheet (PDF)
NCP186AMN080TBG
800mV Positive Fixed DFN-12-EP(4x4) Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
DFN-12-EP(4x4)ROHS3 CompliantActive
LDO Regulator - Fast Transient Response, Low Voltage, 1A
- Manufacturer
- onsemi
- Manufacturer part #
- NCP186AMN080TBG
- Store part #
- C892281
- Package / case
- DFN-12-EP(4x4)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
206 in stock
#C892281
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹91.92 | ₹91.92 |
| 10+ | ₹73.89 | ₹738.90 |
| 30+ | ₹64.97 | ₹1,949.10 |
| 100+ | ₹56.28 | ₹5,628.00 |
| 500+ | ₹50.86 | ₹25,430.00 |
| 1,000+ | ₹48.25 | ₹48,250.00 |
1 × ₹91.92
₹91.92
excl. GST
₹108.47 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NCP186AMN080TBG
₹91.92 for 1 + GST
Specifications
- Output Voltage
- 800mV
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 90uA
- Output Configuration
- Positive
- Operating Voltage
- 5.5V
- Output Current
- 1A
- Output Type
- Fixed
- Features
- Enable control;Built-in soft-start;Operating status indication;Over Current Protection;Output discharge;Thermal shutdown;Short Circuit Protection
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.18 g
Overview
The NCP186x series are CMOS LDO regulators featuring 1 A output current. The input voltage is as low as 1.8 V and the output voltage can be set from 0.8 V.
Applications
- Battery Powered Equipment
- Portable Communication Equipment
- Cameras, Image Sensors and Camcorders
Key features
- Operating Input Voltage Range: 1.8 V to 5.5 V
- Output Voltage Range: 0.8 to 3.9 V
- Fixed or Adjustable Output Voltage Applications
- Quiescent Current typ. 90 μA
- Low Dropout: 100 mV typ. at 1 A, ΔV_OUT = 3.0 V
- High Output Voltage Accuracy ±1%
- Stable with Small 1 μF Ceramic Capacitors
- Over−current Protection
- Built−in Soft Start Circuit to Suppress Inrush Current
- Thermal Shutdown Protection: 165 °C
- With (NCP186A) and Without (NCP186B) Output Discharge Function
- Available in XDFN8 1.2x1.6 mm & DFN12 4x4 mm Packages
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
