NCV0372BDWR2G
1A 1 15mV 1.4V/us 90dB 500nA 1.4MHz SOIC-16 Instrumentation, Op Amps, Buffer Amps RoHS
SOIC-16ROHS3 CompliantActive
1.0 A Output Current, Dual Power Operational Amplifiers
- Manufacturer
- onsemi
- Manufacturer part #
- NCV0372BDWR2G
- Store part #
- C463359
- Package / case
- SOIC-16
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,028 in stock
#C463359
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹169.71 | ₹169.71 |
| 10+ | ₹139.51 | ₹1,395.10 |
| 30+ | ₹123.00 | ₹3,690.00 |
| 100+ | ₹104.31 | ₹10,431.00 |
| 500+ | ₹96.05 | ₹48,025.00 |
| 1,000+ | ₹92.15 | ₹92,150.00 |
1 × ₹169.71
₹169.71
excl. GST
₹200.26 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
NCV0372BDWR2G
₹169.71 for 1 + GST
Specifications
- Output Current
- 1A
- Number of Channels
- 1
- Vos - Input Offset Voltage
- 15mV
- Slew Rate
- 1.4V/us
- Input Offset Current(Ios)
- 10nA
- Operating Temperature
- -40℃~+125℃
- Common Mode Rejection Ratio(CMRR)
- 90dB
- Ib - Input Bias Current
- 500nA
- Input Offset Voltage Drift(Vos TC)
- 20uV/℃
- Gain Bandwidth Product
- 1.4MHz
- Input Voltage Noise Density
- 22nV/√Hz@100kHz
- Dual Supply
- -40V~40V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.521 g
Overview
The TCA0372 is a monolithic circuit intended for use as a power operational amplifier in a wide range of applications, including servo amplifiers and power supplies. No deadband crossover distortion provides better performance for driving coils.
Applications
- servo amplifiers
- power supplies
Key features
- Output Current to 1.0 A
- Slew Rate of 1.3 V/µs
- Wide Bandwidth of 1.1 MHz
- Internal Thermal Shutdown
- Single or Split Supply Operation
- Excellent Gain and Phase Margins
- Common Mode Input Includes Ground
- Zero Deadband Crossover Distortion
- NCV devices are AEC−Q100 Qualified and PPAP Capable
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
