onsemi

NCV321SN3T1G

60mA 1 9mV 1V/us 65dB 1nA 130uA 1MHz Rail-to-rail output TSOP-5 Instrumentation, Op Amps, Buffer Amps RoHS

TSOP-5ROHS3 CompliantActive

Manufacturer: onsemi
Manufacturer part #: NCV321SN3T1G
Store part #: C603904
Package / case: TSOP-5
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

100 in stock

#C603904

Stock & price checked 9 days ago

Quantity	Unit price	Pack price
1+	₹124.69	₹124.69
10+	₹101.62	₹1,016.20
30+	₹90.19	₹2,705.70
100+	₹75.79	₹7,579.00
500+	₹68.81	₹34,405.00
1,000+	₹65.42	₹65,420.00

Quantity (min 1)

1 × ₹124.69

₹124.69

excl. GST

₹147.13 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

NCV321SN3T1G

₹124.69 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Output Current: 60mA
Number of Channels: 1
Vos - Input Offset Voltage: 9mV
Slew Rate: 1V/us
Input Offset Current(Ios): 1nA
Operating Temperature: -40℃~+125℃
Common Mode Rejection Ratio(CMRR): 65dB
Ib - Input Bias Current: 1nA
Input Offset Voltage Drift(Vos TC): 5uV/℃
Quiescent Current: 130uA
Gain Bandwidth Product: 1MHz
Input Voltage Noise Density: 50nV/√Hz@50kHz
Rail to Rail: Rail-to-rail output
Single Supply: 2.7V~5.5V

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.1 g
