NCV7808BD2TR4G
8V Positive Fixed D2PAK Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
D2PAKROHS3 CompliantActive
- Manufacturer
- onsemi
- Manufacturer part #
- NCV7808BD2TR4G
- Store part #
- C898782
- Package / case
- D2PAK
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C898782
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹136.94 | ₹136.94 |
| 10+ | ₹133.95 | ₹1,339.50 |
| 30+ | ₹131.82 | ₹3,954.60 |
| 100+ | ₹129.69 | ₹12,969.00 |
1 × ₹136.94
₹136.94
excl. GST
₹161.59 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 800 per reel
NCV7808BD2TR4G
₹136.94 for 1 + GST
Specifications
- Output Voltage
- 8V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃
- Supply Current (Iq)
- 3.3mA
- Output Configuration
- Positive
- Operating Voltage
- 35V
- Output Current
- 1A
- Features
- Short Circuit Protection;Thermal shutdown;Over Current Protection
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 800 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.01 g
Overview
These voltage regulators are monolithic integrated circuits designed as fixed−voltage regulators for a wide variety of applications including local, on−card regulation. These regulators employ internal current limiting, thermal shutdown, and safe−area compensation. With adequate heatsinking they can deliver output currents in excess of 1.0 A. Although designed primarily as a fixed voltage regulator, these devices can be used with external components to obtain adjustable voltages and currents.
Key features
- Output Current in Excess of 1.0 A
- No External Components Required
- Internal Thermal Overload Protection
- Internal Short Circuit Current Limiting
- Output Transistor Safe−Area Compensation
- Output Voltage Offered in 1.5%, 2% and 4% Tolerance
- Available in Surface Mount D²PAK−3, DPAK−3 and Standard 3−Lead Transistor Packages
- NCV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q100 Qualified and PPAP Capable
- These are Pb−Free Devices
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | L7808ABD2T-TR#C15078ST · TO-263-2 | ST | TO-263-2 | 10,115 | ₹93.63 · 10,115 in stock | View |
 | CJ7808B-TGN-ARG#C20622089JSCJ · TO-263-2L | JSCJ | TO-263-2L | 40 | ₹25.12 · 40 in stock | View |
 | L7808CD2T(UMW)#C7394045UMW · TO-263 | UMW | TO-263 | 930 | ₹32.32 · 930 in stock | View |
 | L7808CD2T-TR#C126455ST · D2PAK | ST | D2PAK | 974 | ₹89.40 · 974 in stock | View |
 | LM7808CS2/TR#C7432233HGSEMI · TO-263-2 | HGSEMI | TO-263-2 | 115 | ₹39.41 · 115 in stock | View |
