NL17SZ14DFT2G

Schmitt trigger 1.65V~5.5V 5.9ns@5V,50pF 1uA 1 SOT-353 Gates and Inverters RoHS

SOT-353ROHS3 CompliantActive

Single Inverter with Schmitt Trigger

Manufacturer: onsemi
Manufacturer part #: NL17SZ14DFT2G
Store part #: C113256
Package / case: SOT-353
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

5,040 in stock

#C113256

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
10+	₹7.79	₹77.90
100+	₹6.17	₹617.00
300+	₹5.36	₹1,608.00
3,000+	₹4.74	₹14,220.00
6,000+	₹4.26	₹25,560.00
9,000+	₹4.01	₹36,090.00

Quantity (min 10, multiples of 10)

10 × ₹7.79

₹77.90

excl. GST

₹91.92 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

NL17SZ14DFT2G

₹77.90 for 10 + GST

Specifications

Input Type: Schmitt trigger
Logic Family: 17SZ
Voltage - Supply: 1.65V~5.5V
Propagation Delay: 5.9ns@5V,50pF
Features: Power shutdown protection;Noise suppression function
Operating Temperature: -55℃~+125℃
Input Logic Level - Low: 200mV~1.2V
Input Logic Level - High: 1.4V~3.6V
Quiescent Current(Iq): 1uA
Number of Channels: 1
Current - Output High(IOH): 32mA
Current - Output Low(IOL): 32mA

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.029 g

Overview

The NL17SZ14 is a single inverter with Schmitt trigger in three tiny footprint packages. The device performs much as LCX multi−gate products in speed and drive.

Key features

Tiny SOT−353, SOT−553 and SOT−953 Packages
Source/Sink 24 mA at 3.0 V
Over−Voltage Tolerant Inputs and Outputs
Pin For Pin with NC7SZ14
Designed for 1.65 V to 5.5 V VCC Operation
Chip Complexity: FET = 20
NLV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q100 Qualified and PPAP Capable
These Devices are Pb−Free and are RoHS Compliant
