HGSEMI

OP27EN

3.8mA 8MHz 10uV 28nA 100dB DIP-8 Instrumentation, Op Amps, Buffer Amps

DIP-8RoHSActive

Low-noise, high-speed, and precise operational amplifier

Manufacturer: HGSEMI
Manufacturer part #: OP27EN
Store part #: C47411535
Package / case: DIP-8
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tube-packed

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,643 in stock

#C47411535

Stock & price checked 2 days ago

Quantity	Unit price	Pack price
1+	₹107.14	₹107.14
10+	₹96.70	₹967.00
50+	₹91.05	₹4,552.50
100+	₹84.54	₹8,454.00
500+	₹81.71	₹40,855.00
1,000+	₹80.41	₹80,410.00

Quantity (min 1)

1 × ₹107.14

₹107.14

excl. GST

₹126.43 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 50 per tube

OP27EN

₹107.14 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Quiescent Current: 3.8mA
Gain Bandwidth Product: 8MHz
Vos - Input Offset Voltage: 10uV
Input Offset Current(Ios): 8nA
Input Voltage Noise Density: 3.5nV/√Hz@10Hz
Operating Temperature: 0℃~+70℃
Ib - Input Bias Current: 28nA
Common Mode Rejection Ratio(CMRR): 100dB
Dual Supply: -18V~-3V;3V~18V
Input Offset Voltage Drift(Vos TC): 1.8uV/℃

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tube-packed
Standard pack: 50 / Tube
Sold per: Piece
Minimum order: 1
Unit weight: 0.823 g

Overview

The OP27 is a high-precision op-amp with a maximum offset voltage of 150μV and a gain of 200V/mV. It is therefore particularly well-suited for instrumentation and similar applications. With a wide input voltage range of ±13V and a CMRR exceeding 100dB, the OP27 maintains excellent linearity and gain accuracy even in high closed-loop gain circuits.
