HGSEMI

OP37GDQ3/TR-HG

3.8mA 63MHz 1 30uV 28nA DFN-8(3x3) Instrumentation, Op Amps, Buffer Amps

DFN-8(3x3)RoHSActive

Manufacturer: HGSEMI
Manufacturer part #: OP37GDQ3/TR-HG
Store part #: C52953081
Package / case: DFN-8(3x3)
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,000 in stock

#C52953081

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
1+	₹135.96	₹135.96
10+	₹112.89	₹1,128.90
30+	₹100.32	₹3,009.60
100+	₹86.11	₹8,611.00
500+	₹79.72	₹39,860.00
1,000+	₹76.84	₹76,840.00

Quantity (min 1)

1 × ₹135.96

₹135.96

excl. GST

₹160.43 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 5,000 per reel

OP37GDQ3/TR-HG

₹135.96 for 1 + GST

Specifications

Quiescent Current: 3.8mA
Gain Bandwidth Product: 63MHz
Number of Channels: 1
Vos - Input Offset Voltage: 30uV
Input Offset Current(Ios): 8nA
Input Voltage Noise Density: 3.2nV/√Hz@1kHz
Operating Temperature: -40℃~+85℃
Ib - Input Bias Current: 28nA
Input Offset Voltage Drift(Vos TC): 1.8uV/℃

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 5,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.06 g

Overview

The OP37 is a high-precision op-amp with a maximum offset voltage of 100 μV and a gain of 200 V/mV. This makes it particularly well-suited for instrumentation and similar applications. With a wide input voltage range of ±13 V and a CMRR exceeding 100 dB, the OP37 maintains excellent linearity and gain accuracy even in high closed-loop gain circuits.
