PT2466
1.8V~5V SOP-8 Motor Drivers, Controllers
PT2466 1.8A H-Bridge Motor Driver for Low-Voltage and Battery-Powered Applications
- Manufacturer
- PTC
- Manufacturer part #
- PT2466
- Store part #
- C126409
- Package / case
- SOP-8
- Category
- Motor Drivers, Controllers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,290 in stock
#C126409
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹27.95 | ₹139.75 |
| 50+ | ₹21.94 | ₹1,097.00 |
| 150+ | ₹19.36 | ₹2,904.00 |
| 500+ | ₹16.13 | ₹8,065.00 |
| 2,500+ | ₹13.80 | ₹34,500.00 |
| 5,000+ | ₹12.94 | ₹64,700.00 |
5 × ₹27.95
₹139.75
excl. GST
₹164.91 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
PT2466
₹139.75 for 5 + GST
Specifications
- Features
- Current sensing/regulation function;Active braking function
- Voltage - Supply
- 1.8V~5V
- Operating Temperature
- -40℃~+85℃
- Supply Current (Iq)
- 2nA
- Output Current
- 1.8A
- Peak Current
- 1.9A
- RDS(on)
- 280mΩ
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.103 g
Overview
The PT2466 provides an integrated motor driver for cameras, consumer products, toys and other application with low-voltage or battery-powered motion control. The PT2466 can supply up to 1.8A of output DC current. It operates on a motor power supply (VM) from 0 to 11V and a device power supply voltage (VCC) of 1.8V to 5V. Ultra- low rds-on allows SOP-8 package available. The PT2466 has a PWM (IN1-IN2) input interface Full protections are integrated with over-current protection, under-voltage lockout and overtemperature shutdown.
Applications
- Cameras
- DSLR Lenses
- Consumer Products
- Toys Robotics
Key features
- H-Bridge Motor Driver DC Motor or Other Loads
- Low On-Resistance: HS+LS 280mΩ
- 1.8-A Maximum DC Drive Current
- Separate Motor and Logic Supply Motor VM: 0 to 11V Logic VCC: 1.8V to 5V
- Low-Power Sleep Mode 10nA with IVM and IVCC
- Small Package and Footprint 8-Pin DFN with Thermal PAD (2.0 X 2.0 mm) 8-Pin SOP
- Protection Features VCC Under-voltage Lockout Over-Current Protection Thermal Shutdown
