RUNIC

RS1G02XF5

1uA 1.65V~5.5V 4.1ns@3.3V,50pF SOT-23-5 Gates and Inverters

SOT-23-5RoHSActive

Manufacturer: RUNIC
Manufacturer part #: RS1G02XF5
Store part #: C42459499
Package / case: SOT-23-5
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,590 in stock

#C42459499

Stock & price checked 26 h ago

Quantity	Unit price	Pack price
10+	₹9.96	₹99.60
100+	₹7.89	₹789.00
300+	₹6.84	₹2,052.00
3,000+	₹6.06	₹18,180.00
6,000+	₹5.42	₹32,520.00
9,000+	₹5.11	₹45,990.00

Quantity (min 10, multiples of 10)

10 × ₹9.96

₹99.60

excl. GST

₹117.53 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

RS1G02XF5

₹99.60 for 10 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Features: Local shutdown mode;Overvoltage-tolerant input
Input Logic Level - Low: 700mV;800mV
Operating Temperature: -40℃~+125℃
Input Logic Level - High: 1.7V;2V
Output Logic Level - High: 2.4V;2.3V
Quiescent Current(Iq): 1uA
Voltage - Supply: 1.65V~5.5V
Number of Channels: 1;2
Current - Output High(IOH): 32mA
Output Logic Level - Low: 550mV
Propagation Delay: 4.1ns@3.3V,50pF
Current - Output Low(IOL): 32mA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.043 g

Overview

RS1G02 is a single 2-input positive-NOR gate designed for 1.65V to 5.5V VCC operation. The device performs the Boolean function Y = A+B (overbar) or Y = Ā · B̄ in positive logic. The device is fully specified for partial-power-down applications using Ioff. The Ioff circuit disables the outputs, preventing damaging current backflow when the device is powered down. The RS1G02 is offered in green SOT23-5 and SC70-5 packages and is rated for operation over the -40°C to +125°C ambient temperature range.
