RZ7899-MS
3V~30V SOP-8 Motor Drivers, Controllers
DC bidirectional motor drive circuit
- Manufacturer
- MSKSEMI
- Manufacturer part #
- RZ7899-MS
- Store part #
- C22462553
- Package / case
- SOP-8
- Category
- Motor Drivers, Controllers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
15,778 in stock
#C22462553
Stock & price checked 42 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹79.37 | ₹79.37 |
| 10+ | ₹63.49 | ₹634.90 |
| 30+ | ₹55.88 | ₹1,676.40 |
| 100+ | ₹48.92 | ₹4,892.00 |
| 500+ | ₹47.61 | ₹23,805.00 |
| 1,000+ | ₹46.53 | ₹46,530.00 |
1 × ₹79.37
₹79.37
excl. GST
₹93.66 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
RZ7899-MS
₹79.37 for 1 + GST
Specifications
- Number of H-bridges
- 1
- Features
- Current sensing/regulation function;Active braking function
- Technology
- Yes
- Voltage - Supply
- 3V~30V
- Operating Temperature
- -25℃~+85℃
- Supply Current (Iq)
- 1mA
- Output Current
- 6A
- RDS(on)
- 80mΩ
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.127 g
Overview
RZ7899-MS is a DC bidirectional motor driver IC suitable for toy motor drives, automatic valve motor drives, electromagnetic door lock drives, and similar applications. It features two logic input terminals to control motor forward, reverse, and braking operations. The IC offers excellent noise immunity, ultra-low standby current, and low output on-resistance. It also integrates built-in diodes to suppress reverse surge current from inductive loads. The RZ7899-MS comes in an SOP-8 package, complies with RoHS standards, and features a 100% lead-free lead frame.
Applications
- Electronic locks
- Toys
- Wireless charging robots
Key features
- Single brushed DC motor drive
- Ultra-low standby current, <1uA
- Low RDS(ON) resistance
- Maximum continuous output current 6.0A
- Operating voltage range: 3.0V - 30V
- Emergency stop function
- Thermal shutdown protection
- Overcurrent limiting and short-circuit protection
- Package: SOP8
