SC8002B

6.5mA 2V~5V 1-Channel 2.5Wx1@4Ω SOP-8 Audio Amplifiers RoHS

SOP-8ROHS CompliantActive

3W Audio Power Amplifier IC

Manufacturer: FM
Manufacturer part #: SC8002B
Store part #: C82124
Package / case: SOP-8
Category: Audio Amplifiers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

24,670 in stock

#C82124

Stock & price checked 7 days ago

Quantity	Unit price	Pack price
10+	₹10.16	₹101.60
100+	₹8.07	₹807.00
300+	₹7.03	₹2,109.00
1,000+	₹6.24	₹6,240.00
4,000+	₹4.97	₹19,880.00
8,000+	₹4.66	₹37,280.00

Quantity (min 10, multiples of 10)

10 × ₹10.16

₹101.60

excl. GST

₹119.89 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 4,000 per reel

SC8002B

₹101.60 for 10 + GST

Specifications

Quiescent Current: 6.5mA
Voltage - Supply: 2V~5V
Features: Enable/shutdown function
Total Harmonic Distortion + Noise (THD+N): 0.25%
Operating Temperature: -40℃~+85℃
Speaker Channels: 1-Channel
Output Power: 2.5Wx1@4Ω
Power Supply Rejection Ratio (PSRR): 60dB

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 4,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.182 g

Overview

SC8002B is an audio power amplifier IC with shutdown mode. When operating at 5V supply voltage, the maximum output power into a 4Ω load is 2.5W. For portable devices, when VDD is applied to the shutdown pin, SC8002B enters shutdown mode with extremely low power consumption — quiescent current IQ is only 0.6uA. SC8002B is an audio power amplifier IC designed for high-power, high-fidelity applications. It requires minimal external components and operates from a supply voltage of 2.0V~5.0V.
