SN65EPT22DR

1 2 SOIC-8 Translators, Level Shifters RoHS

SOIC-8ROHS3 CompliantActive

Dual LVTTL/LVCMOS to Differential LVPECL Buffer

Manufacturer: TI
Manufacturer part #: SN65EPT22DR
Store part #: C2864611
Package / case: SOIC-8
Category: Translators, Level Shifters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

996 in stock

#C2864611

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
1+	₹374.22	₹374.22
10+	₹330.87	₹3,308.70
30+	₹308.75	₹9,262.50
100+	₹279.05	₹27,905.00
500+	₹268.42	₹1,34,210.00
1,000+	₹263.87	₹2,63,870.00

Quantity (min 1)

1 × ₹374.22

₹374.22

excl. GST

₹441.58 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

SN65EPT22DR

₹374.22 for 1 + GST

Specifications

output type: Differential
Output Signal: LVPECL
Input Signal: LVCMOS;LVTTL
Operating Temperature: -40℃~+85℃
Voltage - Supply: 3V~3.6V;-
Number of Elements: 1
Channel Type: Unidirectional
Number of Circuits: 2

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: 5A991B1
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.11 g

Overview

The SN65EPT22 is a low power dual LVTTL to LVPECL translator device. The device includes circuitry to maintain known logic HIGH level when inputs are in open condition. The SN65EPT22 is housed in an industry standard SOIC-8 package and is also available in TSSOP-8 package option.

Applications

Data and Clock Transmission Over Backplane
Signaling Level Conversion

Key features

Dual 3.3V LVTTL to LVPECL Buffer Operating Range – LVPECL VCC = 3.0 V to 3.6 V With GND = 0 V
Support for Clock Frequencies to 2.0 GHz (typ)
420 ps Typical Propagation Delay
Deterministic HIGH Output Value for Open Input Conditions
Built-in Temperature Compensation
Drop in Compatible to MC100ELT23
PNP Single Ended Inputs for Minimal Loading
