SN74ACT32PWR
TTL-compatible CMOS 4.5V~5.5V 9ns@5V,50pF 2uA TSSOP-14 Gates and Inverters RoHS
TSSOP-14ROHS3 CompliantActive
QUADRUPLE 2-INPUT POSITIVE-OR GATES
- Manufacturer
- TI
- Manufacturer part #
- SN74ACT32PWR
- Store part #
- C2864110
- Package / case
- TSSOP-14
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,911 in stock
#C2864110
Stock & price checked 15 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹51.44 | ₹51.44 |
| 10+ | ₹40.15 | ₹401.50 |
| 30+ | ₹35.17 | ₹1,055.10 |
| 100+ | ₹29.09 | ₹2,909.00 |
| 500+ | ₹26.26 | ₹13,130.00 |
| 1,000+ | ₹24.75 | ₹24,750.00 |
1 × ₹51.44
₹51.44
excl. GST
₹60.70 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
SN74ACT32PWR
₹51.44 for 1 + GST
Specifications
- Input Type
- TTL-compatible CMOS
- Logic Family
- 74ACT Series
- Voltage - Supply
- 4.5V~5.5V
- Output Logic Level - Low
- 440mV
- Propagation Delay
- 9ns@5V,50pF
- Input Logic Level - Low
- 800mV
- Operating Temperature
- -40℃~+85℃
- Input Logic Level - High
- 2V
- Output Logic Level - High
- 4.4V;3.76V~4.76V
- Quiescent Current(Iq)
- 2uA
- Current - Output High(IOH)
- 24mA
- Number of Channels
- 4;2
- Current - Output Low(IOL)
- 24mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.204 g
Overview
The 'ACT32 devices are quadruple 2-input positive-OR gates. The devices perform the Boolean function Y = A + B or Y = A(overline) • B(overline) in positive logic.
Key features
- Supply voltage range: 4.5V~5.5V
- Inputs withstand up to 5.5V
- Maximum propagation delay tpd of 10ns at 5V
- TTL-compatible inputs
- Available in multiple package types; pins marked NC indicate no internal connection
- Absolute maximum ratings: supply voltage -0.5V~7V, input voltage -0.5V~VCC+0.5V, output voltage -0.5V~VCC+0.5V, input clamp current ±20mA, output clamp current ±20mA, continuous output current ±50mA, continuous current through VCC or GND pins ±200mA, storage temperature range -65℃~150℃
- Thermal resistance by package: D package 86℃/W, DB package 96℃/W, N package 80℃/W, NS package 76℃/W, PW package 113℃/W
- All unused inputs must be tied to VCC or GND during operation to ensure proper device functionality
- RoHS-compliant product options available
