SN74HC05DR
2V~6V 20ns@6V,50pF 2uA 6 SOIC-14 Gates and Inverters RoHS
SOIC-14ROHS3 CompliantActive
HEX INVERTERS WITH OPEN-DRAIN OUTPUTS
- Manufacturer
- TI
- Manufacturer part #
- SN74HC05DR
- Store part #
- C7640
- Package / case
- SOIC-14
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,570 in stock
#C7640
Stock & price checked 24 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹42.81 | ₹42.81 |
| 10+ | ₹33.68 | ₹336.80 |
| 30+ | ₹29.12 | ₹873.60 |
| 100+ | ₹25.22 | ₹2,522.00 |
| 500+ | ₹24.12 | ₹12,060.00 |
| 1,000+ | ₹23.47 | ₹23,470.00 |
1 × ₹42.81
₹42.81
excl. GST
₹50.52 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
SN74HC05DR
₹42.81 for 1 + GST
Specifications
- Logic Family
- 74HC
- Voltage - Supply
- 2V~6V
- Output Logic Level - Low
- 100mV;260mV;400mV
- Propagation Delay
- 20ns@6V,50pF
- Operating Temperature
- -40℃~+85℃
- Input Logic Level - High
- 1.5V~4.2V
- Input Logic Level - Low
- 500mV~1.8V
- Quiescent Current(Iq)
- 2uA
- Current - Output High(IOH)
- 10uA
- Number of Channels
- 6
- Current - Output Low(IOL)
- 5.2mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.264 g
Overview
The 'HC05 devices contain six independent inverters. They perform the Boolean function Y = A(overline) in positive logic. The open- drain outputs require pullup resistors to perform correctly. They may be connected to other open- drain outputs to implement active- low wired- OR or active- high wired- AND functions.
Key features
- Wide Operating Voltage Range of 2 V to 6 V
- Outputs Can Drive Up To 10 LSTTL Loads
- Low Power Consumption, 20 - μA Max Icc
- Typical t(pd) = 8 ns
- ± 4 - mA Output Drive at 5 V
- Low Input Current of 1 A Max
