SN74HC595PWR
2V~6V 1 7.8mA 26ns@6V,50pF Serial-to-Serial or Parallel TSSOP-16 Shift Registers RoHS
TSSOP-16ROHS3 CompliantActive
8-Bit Shift Registers With 3-State Output Registers
- Manufacturer
- TI
- Manufacturer part #
- SN74HC595PWR
- Store part #
- C273642
- Package / case
- TSSOP-16
- Category
- Shift Registers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,48,390 in stock
#C273642
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹18.27 | ₹91.35 |
| 50+ | ₹14.80 | ₹740.00 |
| 150+ | ₹13.03 | ₹1,954.50 |
| 500+ | ₹11.56 | ₹5,780.00 |
| 2,000+ | ₹11.06 | ₹22,120.00 |
| 4,000+ | ₹10.72 | ₹42,880.00 |
5 × ₹18.27
₹91.35
excl. GST
₹107.79 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
SN74HC595PWR
₹91.35 for 5 + GST
Specifications
- Operating temperature
- -40℃~+85℃
- Voltage - Supply
- 2V~6V
- Output Type
- Tri-State
- Current - Output High(IOH)
- 6mA
- Series
- 74HC
- Current - Output Low(IOL)
- 6mA
- Number of Elements
- 1
- Output Current
- 7.8mA
- Features
- Asynchronous clear function;Output enable
- Propagation Delay
- 26ns@6V,50pF
- Function
- Serial-to-Serial or Parallel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.206 g
Overview
The SNx4HC595 devices contain an 8-bit, serial-in, parallel-out shift register that feeds an 8-bit D-type storage register. The storage register has parallel 3- state outputs. Separate clocks are provided for both the shift and storage register. The shift register has a direct overriding clear (SRCLR) input, serial (SER) input, and serial outputs for cascading. When the output-enable (OE) input is high, the outputs are in the high-impedance state.
Applications
- Network Switches
- Power Infrastructure
- LED Displays
- Servers
Key features
- 8-Bit Serial-In, Parallel-Out Shift
- Wide Operating Voltage Range of 2 V to 6 V
- High-Current 3-State Outputs Can Drive Up to 15 LSTTL Loads
- Low Power Consumption: 80 μA (Maximum)
- ICC tpd=13 ns (Typical)
- ±6-mA Output Drive at 5V
- Low Input Current: 1 μA (Maximum)
- Shift Register Has Direct Clear
- On Products Compliant to MIL-PRF-38535, All Parameters Are Tested Unless Otherwise Noted. On All Other Products, Production Processing Does Not Necessarily Include Testing of All Parameters.
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 74HC595MT/TR#C20613246HGSEMI · TSSOP-16 | HGSEMI | TSSOP-16 | 6,395 | ₹15.19 · 6,395 in stock | View |
 | XL74HC595TS#C22359476XINLUDA · TSSOP16 | XINLUDA | TSSOP16 | 5,005 | ₹14.45 · 5,005 in stock | View |
 | HT74HC595ARZ#C2895054HTCSEMI · SOIC-16 | HTCSEMI | SOIC-16 | 1,390 | ₹22.93 · 1,390 in stock | View |
 | 74HC595AMT/TR#C46635755HGSEMI · TSSOP-16 | HGSEMI | TSSOP-16 | 3,530 | ₹15.70 · 3,530 in stock | View |
 | AiP74HC595TA16.TR#C5121351Wuxi I-core Elec · TSSOP-16 | Wuxi I-core Elec | TSSOP-16 | 19,930 | ₹21.84 · 19,930 in stock | View |
