QUADRUPLE 2-INPUT POSITIVE-NOR GATES
- Manufacturer
- TI
- Manufacturer part #
- SN74HCT02DR
- Store part #
- C471050
- Package / case
- SOIC-14
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5,425 in stock
#C471050
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹42.16 | ₹210.80 |
| 50+ | ₹33.34 | ₹1,667.00 |
| 150+ | ₹29.01 | ₹4,351.50 |
| 500+ | ₹25.18 | ₹12,590.00 |
| 2,500+ | ₹24.12 | ₹60,300.00 |
| 5,000+ | ₹23.48 | ₹1,17,400.00 |
5 × ₹42.16
₹210.80
excl. GST
₹248.74 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
SN74HCT02DR
₹210.80 for 5 + GST
Specifications
- Input Type
- TTL-compatible CMOS
- Logic Family
- 74HCT Series
- Voltage - Supply
- 4.5V~5.5V
- Output Logic Level - Low
- 100mV;330mV
- Propagation Delay
- 18ns@5.5V,50pF
- Input Logic Level - Low
- 800mV
- Input Logic Level - High
- 2V
- Operating Temperature
- -40℃~+85℃
- Output Logic Level - High
- 4.4V;3.7V~3.98V
- Quiescent Current(Iq)
- 2uA
- Current - Output High(IOH)
- 4mA
- Number of Channels
- 4;2
- Current - Output Low(IOL)
- 4mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.34 g
Overview
These devices contain four independent 2 - input NOR gates. They perform the Boolean function Y = A（overline）·B（overline） or Y = (A + B)（overline） in positive logic.
Key features
- Operating Voltage Range of 4.5 V to 5.5 V
- Outputs Can Drive Up To 10 LSTTL Loads
- Low Power Consumption, 20 - μA Max ICC
- Typical propagation delay time (tpd) = 10 ns
- ±4 - mA Output Drive at 5 V
- Low Input Current of 1 μA Max
- Inputs Are TTL - Voltage Compatible
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | EM74HCT02D#C49188200EnergyMath · SOP-14L | EnergyMath | SOP-14L | 55 | ₹21.45 · 55 in stock | View |
 | SN74AHCT02DR#C543073TI · SOIC-14 | TI | SOIC-14 | 198 | ₹49.88 · 198 in stock | View |
 | MC74ACT02DG#C897265onsemi · SOIC-14 | onsemi | SOIC-14 | 200 | ₹100.83 · 200 in stock | View |
 | MC74ACT02DR2G#C233593onsemi · SOIC-14 | onsemi | SOIC-14 | 243 | ₹72.77 · 243 in stock | View |
 | SN74128D#C2878602TI · SOIC-14 | TI | SOIC-14 | 16 | ₹801.96 · 16 in stock | View |
