SN74LS05DR(LX)

2V~6V 16ns 2uA 6 SOP-14 Gates and Inverters

SOP-14RoHSActive

Hex Inverter with Open-drain outputs

Manufacturer: lingxingic
Manufacturer part #: SN74LS05DR(LX)
Store part #: C22374094
Package / case: SOP-14
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,775 in stock

#C22374094

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
5+	₹38.98	₹194.90
50+	₹31.06	₹1,553.00
150+	₹27.68	₹4,152.00
500+	₹23.44	₹11,720.00
2,500+	₹21.56	₹53,900.00
5,000+	₹20.43	₹1,02,150.00

Quantity (min 5, multiples of 5)

5 × ₹38.98

₹194.90

excl. GST

₹229.98 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

SN74LS05DR(LX)

₹194.90 for 5 + GST

Specifications

Logic Family: 74LS
Voltage - Supply: 2V~6V
Output Logic Level - Low: 100mV~260mV
Propagation Delay: 16ns
Input Logic Level - High: 1.5V~4.2V
Operating Temperature: -40℃~+125℃
Input Logic Level - Low: 500mV~1.8V
Quiescent Current(Iq): 2uA
Number of Channels: 6
Current - Output High(IOH): 5.2mA
Current - Output Low(IOL): 5.2mA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.245 g

Overview

The SN74LS05 contains six inverters. The outputs of the SN74LS05 are open-drain and can be connected to other open-drain outputs to implement active-LOW wired-OR or active-HIGH wired-AND functions. The open-drain outputs require pull-up resistors to perform correctly.
