SN74LVC1G00DC(LX)
4uA 1.65V~5.5V 13.5ns@5.5V,50pF SOT-353 Gates and Inverters
SOT-353RoHSActive
Single 2-input Nand Gate
- Manufacturer
- lingxingic
- Manufacturer part #
- SN74LVC1G00DC(LX)
- Store part #
- C22469917
- Package / case
- SOT-353
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,800 in stock
#C22469917
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹4.99 | ₹99.80 |
| 200+ | ₹3.89 | ₹778.00 |
| 600+ | ₹3.27 | ₹1,962.00 |
| 3,000+ | ₹2.91 | ₹8,730.00 |
| 9,000+ | ₹2.59 | ₹23,310.00 |
| 21,000+ | ₹2.42 | ₹50,820.00 |
20 × ₹4.99
₹99.80
excl. GST
₹117.76 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SN74LVC1G00DC(LX)
₹99.80 for 20 + GST
Specifications
- Input Logic Level - Low
- 700mV;800mV
- Input Logic Level - High
- 1.7V;2V
- Logic Family
- 74LVC Series
- Operating Temperature
- -40℃~+125℃
- Output Logic Level - High
- 1.2V;1.9V;2.2V;2.3V;3.8V
- Quiescent Current(Iq)
- 4uA
- Voltage - Supply
- 1.65V~5.5V
- Current - Output High(IOH)
- 24mA
- Number of Channels
- 1;2
- Output Logic Level - Low
- 450mV;300mV;400mV;550mV
- Propagation Delay
- 13.5ns@5.5V,50pF
- Current - Output Low(IOL)
- 24mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.043 g
Overview
The SN74LVC1G00 provides the single 2-input NAND function. Input can be driven from either 3.3V or 5V devices. These features allow the use of these devices in a mixed 3.3V and 5V environment.
Key features
- Wide supply voltage range from 1.65V to 5.5V
- ±24mA output drive (VCC = 3.0V)
- CMOS low power consumption
- Input accepts voltages up to 5V
- Specified from -40°C to +125°C
- Packaging information: SOT-23-5/SOT-353
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SN74LVC1G38DC(LX)#C22469924lingxingic · SOT-353 | lingxingic | SOT-353 | 2,540 | ₹8.78 · 2,540 in stock | View |
