TWGMC

SN74LVC1G04DBVR

1.65V~5.5V 3.1ns@5V,15pF 10uA 1 SOT-23-5 Gates and Inverters RoHS

SOT-23-5ROHS CompliantActive

The SN74LVC1G04 is a NOT gate integrated circuit that can perform the mathematical logical operation of Y = A(overline)

Manufacturer: TWGMC
Manufacturer part #: SN74LVC1G04DBVR
Store part #: C5250996
Package / case: SOT-23-5
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

5,250 in stock

#C5250996

Stock & price checked 33 h ago

Quantity	Unit price	Pack price
10+	₹7.29	₹72.90
100+	₹5.95	₹595.00
300+	₹5.29	₹1,587.00
3,000+	₹4.15	₹12,450.00
6,000+	₹3.76	₹22,560.00
9,000+	₹3.56	₹32,040.00

Quantity (min 10, multiples of 10)

10 × ₹7.29

₹72.90

excl. GST

₹86.02 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

SN74LVC1G04DBVR

₹72.90 for 10 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Logic Family: 74LVC
Voltage - Supply: 1.65V~5.5V
Output Logic Level - Low: 10mV;110mV;200mV;350mV
Propagation Delay: 3.1ns@5V,15pF
Features: Power shutdown protection
Operating Temperature: -40℃~+85℃
Output Logic Level - High: 1.64V;1.47V;2.15V;2.73V;4V
Quiescent Current(Iq): 10uA
Number of Channels: 1
Current - Output High(IOH): 32mA
Current - Output Low(IOL): 32mA

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.039 g

Overview
