SN74LVC1G123DCT(LX)
Schmitt trigger TSSOP-8 Multivibrators
Single Re-triggerable Monostable Multivibrator with Schmitt-Trigger Input SN74LVC1G123 (LX)
- Manufacturer
- lingxingic
- Manufacturer part #
- SN74LVC1G123DCT(LX)
- Store part #
- C26159249
- Package / case
- TSSOP-8
- Category
- Multivibrators
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,855 in stock
#C26159249
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹36.86 | ₹184.30 |
| 50+ | ₹29.42 | ₹1,471.00 |
| 150+ | ₹26.25 | ₹3,937.50 |
| 500+ | ₹22.27 | ₹11,135.00 |
| 3,000+ | ₹19.94 | ₹59,820.00 |
| 6,000+ | ₹18.88 | ₹1,13,280.00 |
5 × ₹36.86
₹184.30
excl. GST
₹217.47 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SN74LVC1G123DCT(LX)
₹184.30 for 5 + GST
Specifications
- Input Type
- Schmitt trigger
- Logic Type
- Monostable
- Number Of Channels
- 1
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.118 g
Overview
The SN74LVC1G123 is a single retriggerable monostable multivibrator with Schmitt-trigger inputs. Output pulse width is controlled by three methods: the base pulse width can be designed by selecting external resistor (REXT) and capacitor (CEXT); once triggered, the output pulse width can be extended by retriggering on the falling edge of (A) or the rising edge of (B) — by repeating this process, the output pulse period (Q = HIGH) can be made to meet expectations as closely as desired; a rising edge on CLR can also trigger the circuit.
Key features
- Supply voltage range: 1.65V ~ 5.5V
- ±24mA output drive (VCC = 3.0V)
- CMOS low power consumption
- Retriggerable for extra-long pulses up to 100% duty cycle
- High-impedance I/O when VCC = 0V
- Reset function
- Schmitt-trigger inputs on all inputs
- Inputs accept up to 5.5V signals
- Power-on reset function
- Rated temperature range: -40°C ~ +125°C
- Package: TSSOP8/VSSOP8/XSON8
