SN74LVC1G38DB(LX)
1.65V~5.5V 19.7ns@1.65V,30pF 4uA SOT-23-5 Gates and Inverters
SOT-23-5RoHSActive
Single 2-input Nand Gate (Open-drain)
- Manufacturer
- lingxingic
- Manufacturer part #
- SN74LVC1G38DB(LX)
- Store part #
- C41413106
- Package / case
- SOT-23-5
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,480 in stock
#C41413106
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹9.16 | ₹91.60 |
| 100+ | ₹7.24 | ₹724.00 |
| 300+ | ₹6.28 | ₹1,884.00 |
| 3,000+ | ₹5.56 | ₹16,680.00 |
| 6,000+ | ₹4.99 | ₹29,940.00 |
| 9,000+ | ₹4.70 | ₹42,300.00 |
10 × ₹9.16
₹91.60
excl. GST
₹108.09 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SN74LVC1G38DB(LX)
₹91.60 for 10 + GST
Specifications
- output type
- Open-drain
- Logic Family
- 74LVC
- Voltage - Supply
- 1.65V~5.5V
- Output Logic Level - Low
- 100mV~800mV
- Propagation Delay
- 19.7ns@1.65V,30pF
- Features
- Rear drive protection;Overvoltage-tolerant input
- Operating Temperature
- -40℃~+125℃
- Quiescent Current(Iq)
- 4uA
- Number of Channels
- 1;2
- Current - Output Low(IOL)
- 32mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.048 g
Overview
The SN74LVC1G38 provides a 2-input NAND function. Inputs can be driven from either 3.3 V or 5 V devices. This feature allows the use of this device as translator in a mixed 3.3 V and 5 V environment.
Key features
- Wide supply voltage range from 1.65V to 5.5V
- 5V tolerant outputs for interfacing with 5V logic
- ±24 mA output drive (V_CC = 3.0V)
- CMOS low power consumption
- Open drain outputs
- Specified from -40 ℃ to +125 ℃
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SN74LVC1G00DB(LX)#C22384790lingxingic · SOT-23-5 | lingxingic | SOT-23-5 | 900 | ₹4.99 · 900 in stock | View |
