TOSHIBA

TB6568KQ(O,8)

10V~45V HSIP-7 Motor Drivers, Controllers

HSIP-7RoHSActive

Full-Bridge DC Motor Driver IC

Manufacturer: TOSHIBA
Manufacturer part #: TB6568KQ(O,8)
Store part #: C5349736
Package / case: HSIP-7
Category: Motor Drivers, Controllers
Packaging: Tube-packed

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,586 in stock

#C5349736

Stock & price checked 30 h ago

Quantity	Unit price	Pack price
1+	₹335.23	₹335.23
10+	₹304.25	₹3,042.50
25+	₹284.89	₹7,122.25
100+	₹265.09	₹26,509.00
500+	₹256.05	₹1,28,025.00
1,000+	₹252.19	₹2,52,190.00

Quantity (min 1)

1 × ₹335.23

₹335.23

excl. GST

₹395.57 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 25 per tube

TB6568KQ(O,8)

₹335.23 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Number of H-bridges: 1
Features: Interleaved conduction protection;Current sensing/regulation function;Active braking function
Voltage - Supply: 10V~45V
Technology: Yes
Operating Temperature: -40℃~+85℃
Supply Current (Iq): 2.5mA
Output Current: 1.5A
Peak Current: 3A
RDS(on): 550mΩ

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tube-packed
Standard pack: 25 / Tube
Sold per: Piece
Minimum order: 1
Unit weight: 3.07 g

Overview

The TB6568KQ is a full-bridge DC motor driver IC employing the MOS process for output power transistors. The low ON-resistance MOS process and PWM control enables driving DC motors with high thermal efficiency. Four operating modes are selectable via IN1 and IN2: clockwise (CW), counterclockwise (CCW), Short Brake and Stop.
