TC7S08F

10uA 2V~6V 17ns@6.0V,50pF SOT-23-5 Gates and Inverters

SOT-23-5RoHSActive

2-input AND Gate

Manufacturer: TECH PUBLIC
Manufacturer part #: TC7S08F
Store part #: C19829491
Package / case: SOT-23-5
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

14,870 in stock

#C19829491

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
10+	₹7.46	₹74.60
100+	₹5.90	₹590.00
300+	₹5.12	₹1,536.00
3,000+	₹4.54	₹13,620.00
6,000+	₹4.06	₹24,360.00
9,000+	₹3.82	₹34,380.00

Quantity (min 10, multiples of 10)

10 × ₹7.46

₹74.60

excl. GST

₹88.03 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

TC7S08F

₹74.60 for 10 + GST

Specifications

Logic Family: TC7S
Operating Temperature: -40℃~+85℃
Input Logic Level - High: 1.5V;3.15V;4.2V
Input Logic Level - Low: 500mV;1.35V;1.8V
Output Logic Level - High: 1.9V;4.4V;5.9V
Quiescent Current(Iq): 10uA
Voltage - Supply: 2V~6V
Number of Channels: 2;2
Propagation Delay: 17ns@6.0V,50pF
Output Logic Level - Low: 100mV;330mV

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.034 g

Overview

TC7S08F are CMOS 2-input AND gate ICs. They realize a high speed operation similar to LSTTL with a lower power consumption by CMOS features. An inner circuit structure of 3-stages logic gates obtains wider noise immunity and constant output.

Applications

Voltage Level Shifting
General Purpose Logic
Power Down Signal Isolation
Wide array of products such as: PCs, Networking, Notebooks, Netbooks, PDAs, Tablet Computers, E-readers, Computer Peripherals, Hard Drives, CD/DVDROM
TV, DVD, DVR, Set-Top Box
Cell Phones, Personal Navigation / GPS
MP3 Players, Cameras, Video Recorders

Key features

Power voltage range: 2.0 ~ 6.0V
Operation temp. range: -40 ~ +85°C
|IOH| = IOL = 2mA (min)
ESD Protection Exceeds ESD 22 - 2000-V Human-Body Model (A114-A) - 1000-V Charged-Device Model (C101)
SOT23-5 Package Available
