TOSHIBADatasheet (PDF)
TC7SH08F,LJ(CT
2V~5.5V 7.9ns@5V,50pF 2uA SC-74A(SOT-753) Gates and Inverters RoHS
SC-74A(SOT-753)ROHS3 CompliantActive
- Manufacturer
- TOSHIBA
- Manufacturer part #
- TC7SH08F,LJ(CT
- Store part #
- C5156518
- Package / case
- SC-74A(SOT-753)
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,350 in stock
#C5156518
Stock & price checked 26 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹19.74 | ₹98.70 |
| 50+ | ₹15.40 | ₹770.00 |
| 150+ | ₹13.55 | ₹2,032.50 |
| 500+ | ₹10.70 | ₹5,350.00 |
| 3,000+ | ₹9.67 | ₹29,010.00 |
| 6,000+ | ₹9.05 | ₹54,300.00 |
5 × ₹19.74
₹98.70
excl. GST
₹116.47 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TC7SH08F,LJ(CT
₹98.70 for 5 + GST
Specifications
- Logic Family
- TC7SH Series
- Voltage - Supply
- 2V~5.5V
- Output Logic Level - Low
- 0V~100mV;360mV
- Propagation Delay
- 7.9ns@5V,50pF
- Features
- Overvoltage-tolerant input
- Input Logic Level - Low
- 500mV
- Operating Temperature
- -40℃~+85℃
- Input Logic Level - High
- 1.5V
- Output Logic Level - High
- 3.94V;4.4V~4.5V
- Quiescent Current(Iq)
- 2uA
- Current - Output High(IOH)
- 8mA
- Number of Channels
- 1;2
- Current - Output Low(IOL)
- 8mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.075 g
