TC7SU04FU.LF
₹102.20 for 5 + GST
Specifications
- Voltage - Supply
- 2V~6V
- Output Logic Level - Low
- 330mV
- Propagation Delay
- 9ns@6V,50pF
- Input Logic Level - High
- 1.7V;3.6V;4.8V
- Operating Temperature
- -40℃~+85℃
- Input Logic Level - Low
- 300mV;900mV;1.2V
- Output Logic Level - High
- 5.63V
- Quiescent Current(Iq)
- 10uA
- Number of Channels
- 1
- Current - Output High(IOH)
- 2.6mA
- Current - Output Low(IOL)
- 2.6mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.029 g
Overview
The TC7SU04 is a high speed C²MOS Inverter fabricated with silicon gate C²MOS technology. It achieves high speed operation similar to equivalent LSTTL while maintaining the C²MOS low power dissipation. The internal circuit is composed of single stages inverter, it can be applied for crystal oscillation. The input is equipped with protection circuits against static discharge or transient excess voltage. Output currents are 1/2 compared to TC74HC series models.
Key features
- High speed: tpd = 7 ns (typ.) at VCC = 5 V
- Low power dissipation: ICC = 1.0 μA (max) at Ta = 25℃
- High noise immunity: VNI H = VNI L = 10% VCC (min)
- Output drive capability: 5 LSTTL loads
- Symmetrical output impedance: |OH| = |OL| = 2 mA (min)
- Balanced propagation delay time: tpLH ≃ tpHL
- Wide operating voltage range: VCC (opr) = 2 to 6 V
