UMW
XC6206P332MRLinear Voltage Regulator IC Positive Fixed 1 Output 250mA SOT-23
From
₹2.53
18,64,000 in stock
TECH PUBLICDatasheet (PDF)
TP5108E23E-30
3V Positive Fixed SOT-23-5 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
SOT-23-5RoHSActive
500mA High PSRR Voltage Regulators
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- TP5108E23E-30
- Store part #
- C907846
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,090 in stock
#C907846
Stock & price checked 42 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹10.41 | ₹104.10 |
| 100+ | ₹8.33 | ₹833.00 |
| 300+ | ₹7.30 | ₹2,190.00 |
| 3,000+ | ₹5.77 | ₹17,310.00 |
| 6,000+ | ₹5.15 | ₹30,900.00 |
| 9,000+ | ₹4.83 | ₹43,470.00 |
10 × ₹10.41
₹104.10
excl. GST
₹122.84 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TP5108E23E-30
₹104.10 for 10 + GST
Specifications
- Output Voltage
- 3V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+85℃
- Supply Current (Iq)
- 80uA
- Output Configuration
- Positive
- Output Current
- 500mA
- Operating Voltage
- 7V
- Features
- Enable control
- Output Type
- Fixed
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.044 g
Overview
The TP5108E is a high-performance, 500mA LDO regulator, offering extremely high PSRR and ultra-low dropout. Ideal for portable RF and wireless applications with demanding performance and space requirements. The TP5108E is available in 5pin SOT23-5 Package. the output standards of 1.2V 1.5V 1.8V 2.5V 2.8V 3.0V 3.3V
Applications
- CDM/G-SM mobile phone
- PDAs
- MP3 Audio/Video equipment
Key features
- Quiescent Current: 80uA
- PSRR: 72dB@1KHz
- < 1uA current at shutdown mode
- Output voltage accuracy: tolerance ±2%
- Output current: 500mA(Typ.) SOT23-5 package
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | WL2803E30#C41408121TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 155 | ₹7.22 · 155 in stock | View |
 | TPRT9013-30GB#C587159TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 15,620 | ₹10.44 · 15,620 in stock | View |
 | TP9001-30S5#C708749TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 245 | ₹5.03 · 245 in stock | View |
 | TP2028-3.0YN5G#C907844TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 3,050 | ₹9.29 · 3,050 in stock | View |
 | SPX3819M5-L-3-0#C23380894TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 2,155 | ₹18.87 · 2,155 in stock | View |
