XINLUDA

XL74LS00

4.75V~5.25V 25ns@5V,15pF SOP-14 Gates and Inverters

SOP-14RoHSActive

Quadruple 2-Input NAND Gates

Manufacturer: XINLUDA
Manufacturer part #: XL74LS00
Store part #: C609793
Package / case: SOP-14
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,255 in stock

#C609793

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹24.67	₹123.35
50+	₹19.25	₹962.50
150+	₹16.93	₹2,539.50
500+	₹14.04	₹7,020.00
2,500+	₹12.74	₹31,850.00
5,000+	₹11.97	₹59,850.00

Quantity (min 5, multiples of 5)

5 × ₹24.67

₹123.35

excl. GST

₹145.55 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

XL74LS00

₹123.35 for 5 + GST

Specifications

Operating Temperature: 0℃~+70℃
Input Logic Level - Low: 800mV
Input Logic Level - High: 2V
Logic Family: 74LS
Output Logic Level - High: 2.7V
Voltage - Supply: 4.75V~5.25V
Current - Output High(IOH): 400uA
Number of Channels: 4;2
Propagation Delay: 25ns@5V,15pF
Output Logic Level - Low: 500mV;400mV
Current - Output Low(IOL): 8mA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.324 g

Overview

The XD74LS00 andXL74LS00 devices contain 4 independent 2-input NAND gates. The devices perform the Boolean function Y = A(overline) · B(overline) or Y = (A + B)(overline) in positive logic. The XD74LS00/XL74LS00 characterized for operation from 0 ℃ to 70 ℃
