MDD(Microdiode Semiconductor)Datasheet (PDF)
74AHC1G126GW
StandardCMOS 2V~5.5V 1 1 SOT-353 Buffers, Drivers, Receivers, Transceivers
SOT-353RoHSActive
- Manufacturer
- MDD(Microdiode Semiconductor)
- Manufacturer part #
- 74AHC1G126GW
- Store part #
- C53954314
- Package / case
- SOT-353
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,860 in stock
#C53954314
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.03 | ₹80.30 |
| 100+ | ₹6.34 | ₹634.00 |
| 300+ | ₹5.49 | ₹1,647.00 |
| 3,000+ | ₹4.84 | ₹14,520.00 |
| 6,000+ | ₹4.34 | ₹26,040.00 |
| 9,000+ | ₹4.09 | ₹36,810.00 |
10 × ₹8.03
₹80.30
excl. GST
₹94.75 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74AHC1G126GW
₹80.30 for 10 + GST
Specifications
- Input type
- StandardCMOS
- Series
- 74AHC
- Voltage - Supply
- 2V~5.5V
- Output Type
- Tri-State
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Operating Temperature
- -40℃~+125℃
- Number of Elements
- 1
- Quiescent Supply Current
- 10uA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.06 g
Overview
74AHC1G126 and 74AHCT1G126 are single buffer/line drivers with three-state outputs. The inputs are 5 V tolerant, allowing these devices to be used as translators in mixed-voltage environments.
Key features
- Wide supply voltage range: 2.0 V to 5.5 V
- Input overvoltage tolerance up to 5.5 V
- High noise immunity
- CMOS low power consumption
- Latch-up performance exceeds 200 mA
- Symmetrical output impedance
- Balanced propagation delay
- Input levels: 74AHC1G126 CMOS level; 74AHCT1G126 TTL level
- ESD protection: HBM ANSI/ESDA/JEDEC JS-001 Class 3A exceeds 7000 V; CDM ANSI/ESDA/JEDEC JS-002 C3 exceeds 2000 V
- Multiple package options
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| 74AHC1G125GW#C54796856MDD(Microdiode Semiconductor) · SOT-353 | MDD(Microdiode Semiconductor) | SOT-353 | 2,960 | ₹9.26 · 2,960 in stock | View | |
 | 74AHCT1G125GW#C52953352MDD(Microdiode Semiconductor) · SOT-353 | MDD(Microdiode Semiconductor) | SOT-353 | 2,910 | ₹9.62 · 2,910 in stock | View |
 | 74AHC1G07GW#C52140487MDD(Microdiode Semiconductor) · SOT-353 | MDD(Microdiode Semiconductor) | SOT-353 | 2,264 | ₹10.17 · 2,264 in stock | View |
